- Page 1 HG6143D GPON Optical Network Unit Code: MN000004499 Version: A User Manual This document is intended to be used for reference only.
-
Page 2: Operation Safety Rules
Do not lay this equipment on an unsteady base. Product Introduction The HG6143D is an FTTH GPON optical network unit. It provides communication and entertainment service in multiple modes such as data, voice and video, to meet integrated access requirement of families or small enterprises. -
Page 3: Product Type
Supports the authentication modes such as OPEN, SHARED, WPA-PSK, WPA2-PSK, WPA- PSK/WPA2-PSK. Supports the encryption modes such as NONE, WEP, TKIP, AES, and TKIP/AES. Product Type 4 GE interfaces External antenna 1 phone interfaces Wi-Fi interface HG6143D Technical Specification Type Item Description × × × 36.8mm×204mm 149mm(H W D) -
Page 4: Equipment Installation
Equipment Installation The HG6143D can be placed horizontally or vertically on a desk, or hung against the wall. Horizontal desk top mounting * The picture only for you reference! Note: The base is optional and you can choose whether to order it based on your demand. -
Page 5: Interfaces And Connections
Interfaces and Connections Rear panel Phone interface Network interface USB interface 5. Power switch 4. Power interface Power adapter Phone Wi-Fi Side panel Reset key 7. Wireless switch 8. WPS switch Bottom panel 9. Fiber interface Fiber interface... -
Page 6: Indicator Led Description
Indicator LED Description Blinking The equipment is not The equipment is powered — Power status LED (green) powered on. Registration status LED (green) The ONU is activating. The ONU is activated. The ONU is not activated. No optical signals are Optical signals are —... - Page 7 Select the Obtain an IP address automatically mode (recommended). Set to a static IP address in the same network segment of the management IP address (192.168.1.1 by default) of the HG6143D. § IP address: 192.168.1.X (X is a decimal integer between 2 and 253) §...
-
Page 8: Setting Wireless Network
Setting Wireless Network Step1 Select Network in the navigation bar and select Wlan Settings→Advanced or Wlan Settings →5 Advanced in the link bar to open the page for the advanced wireless configuration of the 2.4G or 5G Wi-Fi interface. Step2 Set the parameters of the wireless network, including SSID name, password and authentication and encryption mode. - Page 9 FAQs FAQ1: All indicator LEDs are extinguished after power-on. 1. Check whether the power cable is correctly connected; 2. Check whether the power supply and the power adapter are normal; 3. Check whether the power switch on the device’s rear panel is in the ON position. FAQ2: The device fails to work.
- Page 10 12 months from the date of purchase. The original, dated, bill of sale should be retained as proof of purchase and must be presented to FiberHome when the equipment is to be serviced under the provisions of this warranty.
-
Page 11: Warranty Description
2. Please keep this card properly. No reissuance will be provided if you lose it and it becomes invalid if altered. 3. In the event of a non man-made malfunction during the warranty period, FiberHome will repair or replace this product to its original operating condition free of charge. - Page 12 CHECKER DATE â â are trademarks of FiberHome Telecommunication Technologies Co., Ltd. (Hereinafter referred to as FiberHome). All brand names and product names used in this document are used for identification purposes only and are trademarks or registered trademarks of their respective holders.
