ADSL ROUTER

USER MANUAL

Product name:
ADSL ROUTER
Product model:
HG110
Version: V111
Date: 201406
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HG110 and is the answer not in the manual?

Questions and answers

Related Manuals for FiberHome HG110

Summary of Contents for FiberHome HG110

  • Page 1: Adsl Router

    ADSL ROUTER USER MANUAL Product name: ADSL ROUTER Product model: HG110 Version: V111 Date: 201406...
  • Page 2 NOTICE This document contains proprietary information protected by copyright, and this Manual and all the accompanying hardware, software, and documentation are copyrighted. All rights are reserved. No part of this document may be photocopied or reproduced by mechanical, electronic, or other means in any form. The manufacturer does not warrant that the hardware will work properly in all environments and applications, and makes no warranty or representation, either expressed or implied, with respect to the quality, performance, merchantability, or...

  • Page 3: Table Of Contents

    Content 1.  Overview ..........................1  1.1.  Features ........................1  1.2.  Packet Contents ..................... 4  1.3.  System Requirements ................... 5  1.4.  Factory Defaults ...................... 5  1.5.  Warnings and Cautions ..................5  2.  Hardware Description ......................6  3.  Hardware Installation ......................7  4. ...

  • Page 4: Overview

    Wireless ADSL Router User Manual 1. Overview The HG110 series is a high-performance wireless ADSL Home gate. It combining an DSL modem, an 802.11n wireless router, and 4-port switch in one unit, bringing high-speed wireless Internet connection to a home or office provides. The maximum transmission speed will up to 24Mbps (uplink) and 2.5Mbps (downlink).
  • Page 5 Wireless ADSL Router User Manual  RFC5072 PPP IPv6  RFC2225/RFC1577 Classical IP over ATM  RFC1483 Transparent Bridge  RFC 1483/2684 Bridged Ethernet  RFC 826 RARP  RFC 2684 MER  ATM Forum UNI 3.1/4.0, ATM Adaptation Layer Type 5-AAL5 ...
  • Page 6 Wireless ADSL Router User Manual  NAT Application Level Gateway for popular applications  DHCP Server/Relay/client  RFC 3315/RFC3633 DHCP IPv6  DNS Relay Agent  DMZ support  DDNS support  SNMP v1, v2 support  UPnP (Universal Plug and Play) ...

  • Page 7: Packet Contents

    Wireless ADSL Router User Manual (DoS) protection  ALG (Application-level gateway) for NAT/PAT support  2 Level (User/Admin) Password Authentication to Router  IP Filtering  MAC Filtering  Parental control 1.1.7. VPN Pass-Through  IPSec/PPTP/L2TP Pass-through 1.1.8. QoS  Classification Rules ...

  • Page 8: System Requirements

    Wireless ADSL Router User Manual  Power Adapter  Telephone Line x 2 (1m & 2m)  Ethernet Cable  Base  (User Manual. Quick Installation Guide. Installation software) 1.3. System Requirements Before using this ROUTER, verify that you meet the following requirements: ...

  • Page 9: Hardware Description

    Wireless ADSL Router User Manual  Never install telephone wiring during storm. Avoid using a telephone during an electrical storm. There might be a risk of electric shock from lightening.  Do not install telephone jacks in wet locations and never use the product near water.

  • Page 10: Hardware Installation

    Wireless ADSL Router User Manual On: ADSL link established and active Quick blinking: ADSL is trying to establish a connection Green Slow blinking: No ADSL link On: IP connected Internet Green Blinking: IP traffic is passing thru this device Off: No ADSL connection is present On:The router has passed the WPS function Green...

  • Page 11: Pc Configuration Guide

    Wireless ADSL Router User Manual 1. Using a telephone line to connect the ADSL port of ROUTER to the MODEM port of the splitter, and using a other telephone line connect your telephone to the PHONE port of the splitter, then connect the wall phone jack to the LINE port of the splitter.

  • Page 12: Web-Based Management Guide

    Wireless ADSL Router User Manual as 192.168.1.x (x can be a decimal number from 2 to 254.), and the subnet mask as 255.255.255.0 and the default gateway as 192.168.1.1. Then click “OK”. 6. Configure the “DNS” tab if necessary. For information on the IP address of the DNS server, please consult with your ISP.
  • Page 13 Wireless ADSL Router User Manual 1.click RUN WIZARD and you’ll see the following screen 2.Click NEXT to change the admin account password by entering in a new passwo 3.Click the NEXT to select the appropriate time...
  • Page 14 Wireless ADSL Router User Manual 4.Click NEXT to Select the Internet connection type to connect to your ISP, just choose PPPoE for example here 5.Click NEXT to enter the PPPoE/PPPoA information provided to you by your ISP 6.Click NEXT to save the username and password...

  • Page 15: Internet Access Configuration

    Wireless ADSL Router User Manual 7.Click NEXT to save the current setting. 5.3. Internet Access Configuration From home page, you can find Interface setup option on the above router configuration page.Click Internet and you’ll see the following screen.
  • Page 16 Wireless ADSL Router User Manual 5.3.1. ATM VC ATM settings are used to connect to your ISP. Your ISP provides VPI, VCI settings to you. In this Device, you can totally setup 8 VCs on different encapsulations, if you apply 8 different virtual circuits from y our ISP.
  • Page 17 Wireless ADSL Router User Manual address if it is not in this format. PPPoA/PPPoE Select this option if your ISP requires you to use a PPPoE connection. This option is typically used for DSL services. Select Dynamic PPPoE to obtain an IP address automatically for your PPPoE connection.

  • Page 18: Setting

    Wireless ADSL Router User Manual membership in a multicast group. The ADSL ATU-R supports both IGMP version 1 (IGMP-v1) and IGMP-v2. Select None to disable it. This function is most for IPTV. Note: In the Web configuration page, when you change the parameters, it is not working immediately.
  • Page 19 Wireless ADSL Router User Manual the assignment of IP addresses on your local network (LAN only). 5.5.1. DHCP Server DHCP stands for Dynamic Host Control Protocol. The DHCP Server gives out IP addresses when a device is booting up and request an IP address to be logged on to the network.

  • Page 20: Wireless Setting

    Wireless ADSL Router User Manual contains the range of the IP address that will automatically be assigned to the clients on the network. Starting IP Address The starting IP address for the DHCP server's IP assignment. IP Pool Count The max user pool size. Lease Time The length of time for the IP lease.
  • Page 21 Wireless ADSL Router User Manual SSID The SSID is a unique name to identify the ADSL Router in the wireless LAN. Wireless clients associating to the ADSL Router must have the same SSID.
  • Page 22 Wireless ADSL Router User Manual Broadcast SSID Select No to hide the SSID such that a station can not obtain the SSID through passive scanning. Select Yes to make the SSID visible so a station can obtain the SSID through passive scanning. Channel ID The range of radio frequencies used by IEEE 802.11b/g wireless devices is called a channel.

  • Page 23: Advanced Setup

    Wireless ADSL Router User Manual Status Use the drop down list box to enable or disable MAC address filtering. Action Select Deny Association to block access to the router, MAC addresses not listed will be allowed to access the router. Select Allow Association to permit access to the router, MAC addresses not listed will be denied access to the router.
  • Page 24 Wireless ADSL Router User Manual Enter the parameter that you need,and click SAVE. 5.7.3. NAT Select this option to setup the NAT (Network Address Translation) function for yourADSL router. From Advanced Setup, click NAT Select the parameter that you need,and click SAVE. 5.7.4.
  • Page 25 Wireless ADSL Router User Manual technologies, different LAN ports can be managed by different VLANs. From Advanced Setup, click ADSL and you’ll see the following screen. 5.7.6. PortBinding This option will provide better Portbinding, so that different ports can bind different PVCs.

  • Page 26: Access Management

    Wireless ADSL Router User Manual 5.8. Access management From home page, you can find Advanced Setup option on the above router configuration page. 5.8.1. ACL You may use telnet or Web to remotely manage the ADSL Router. User just needs to enable Telnet or Web and give it an IP address that want to access the ADSL Router.
  • Page 27 Wireless ADSL Router User Manual Enter the parameter that you need, and click SAVE. 5.8.2. Filter Select Telnet, FTP, TFTP, Web, SNMP, Ping to block incoming WAN requests for the corresponding service(s). From Access Management, click Filter and you’ll see the following screen. Enter the parameter that you need, and click SAVE.
  • Page 28 Wireless ADSL Router User Manual From Access Management, click SNMP and you’ll see the following screen. Enter the parameter that you need, and click SAVE. 5.8.4. UPnP From Access Management, click UPnPand you’ll see the following screen. Select the parameter that you need, and click SAVE. 5.8.5.

  • Page 29: Maintenance Guide

    Wireless ADSL Router User Manual 6. Maintenance guide From home page, you can find Maintenance option on the above router configuration page. 6.1. Modify login password configuration interface From Maintenance, click Administration and you’ll see the following screen. Enter your new password and click SAVE. 6.2.

  • Page 30: Factory Default Settings

    Wireless ADSL Router User Manual Select New Firmware Location, you can update the firmware of the CPE. Select the ROMFILE BACKUP, you can back up the rom file. 6.4. Factory Default Settings Warning:Restore the factory setting,your configuration will be lost. From Maintenance, click SysRestart and you’ll see the following screen.

  • Page 31: Safety Precautions

    Wireless ADSL Router User Manual 8. Safety Precautions Follow these announcements below to protect the device from risks and damage caused by fire or electric power.  Use power marked in the volume label.  Use the power adapter packed in the device package. ...

  • Page 32: Appendix: Frequent Asked Questions

    Wireless ADSL Router User Manual power outlet or damaged lines and plugs may cause electric shock or fire accident. Check the power cords regularly. If you find any damage, replace it at once.  Proper space left for heat radiation is necessary to avoid any damage caused by overheating to the device.
  • Page 33 Wireless ADSL Router User Manual Q: When power supply suddenly turned off or changes, is the configuration be the same as before? A:Yes, when you have finished the configuration, you need to press “ Save” button to save configure parameters. And all the parameters have been saved, and will not change when power supply turn off or changed.
  • Page 34 If the cause is not given above, please contact your local sales representative, service representative or distributor for any help needed at the contact information shown below. Fiberhome Telecommunication Technologies Co,Ltd. Address: No. 5dongxin Rd., Hongshan Dist., Wuhan,China Zip code: 430073...
