Epson CaptureOne TM-S1000 Manual

Epson CaptureOne TM-S1000 Manual

Hide thumbs Also See for CaptureOne TM-S1000:

Advertisement

Quick Links

Download this manual
2
Pull out both pocket guide
and ASF/SF guide.
Start Here
Start Here
ove plastic insert.
for the multi feed models)
Single feed models
Document scanner
Note:
Be sure that the guides are
extended completely before
using.
3
Place on a stable, flat surface that extends beyond the
scanner (with guides fully extended) in all directions.
Note:
Document scanner
3
Install the USB
driver.
CAUTION:
Make sure that the power is not supplied to the scanner.
1
Start the TM-S1000 Utility included
on the Utilities & Documents CD.
Insert
Click

Advertisement

loading
Need help?

Need help?

Do you have a question about the CaptureOne TM-S1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Epson CaptureOne TM-S1000

Summary of Contents for Epson CaptureOne TM-S1000

  • Page 1 Install the USB Pull out both pocket guide driver. and ASF/SF guide. Note: CAUTION: Start Here Be sure that the guides are Start Here extended completely before Make sure that the power is not supplied to the scanner. using. Start the TM-S1000 Utility included on the Utilities &...
  • Page 2 Unpack Unpack Remove plastic insert. (only for the multi feed models) For the multi feed models, remove the plastic insert. Make sure you have all the parts shown here. If any parts are missing, contact your reseller. AC Adapter C * Utility &...
  • Page 3 Step to install the USB driver. clothing. Insert checks straight Use only Seiko Epson cartridges. Others may Note: have poor quality or damage the scanner. side on which magne Use up the cartridge before the expiration date are printed facing out printed on the box.

  • Page 4: Install The Usb Driver

    Install the USB driver. CAUTION: Make sure that the power is not supplied to the scanner. Start the TM-S1000 Utility included on the Utilities & Documents CD. Click Insert CAUTION: Starting the TM-S1000 Utility causes the USB driver to be installed. Do not start the TM-S1000 Utility with the scanner connected to a host computer.
  • Page 5 Connect the USB cable to the scanner. Note: Use only the USB cable included with the scanner. Hook the USB cable on the USB cable securing hook (colored blue in the illustration) to prevent the cable from falling off. Connect the DC cable to the scanner. Make sure the power switch is turned off and the AC cable is not connected to the AC outlet.
  • Page 6 Connect the scanner to the computer via the USB cable. Note: If the scanner is connected to a host computer before installing the USB driver, the Found New Hardware Wizard will be displayed. In that case, cancel the wizard and go back to Step to install the USB driver.
  • Page 7 Keep franking cartridges out of reach of children. Use carefully because ink can permanently stain clothing. Use only Seiko Epson cartridges. Others may have poor quality or damage the scanner. Use up the cartridge before the expiration date printed on the box. Dispose of used cartridges in accordance with local regulations.
  • Page 8 Insert checks. CAUTION: For the multi feed models, if the checks are inserted without being aligned, they may not be fed at all, or a paper jam or incorrect feeding of multiple checks may occur. For the single feed models, if more than one check is inserted, a paper jam or incorrect Insert checks straight down with the feeding of multiple checks may occur.
  • Page 9 Then, close scanner cover until it clicks into place. Cleaning the MICR Unit Use an approved Epson MICR cleaner card. KIC Team, Inc. • Waffletechnology (R) MICR cleaning card (model:CS1B15WS) • Epson Check Scanner Cleaning Kit (model:KWEPS-KCS2) Use TM-S1000 Utility & Documents CD or your application for MICR cleaning.

  • Page 10: Specifications

    Type Exclusive franking cartridge (EFC-01) Franking cartridge Ink color Life of ink 18,000 times (based on Epson's standard pattern used for printing.) Power supply +24 V ± 10% Operating Current 1.0 A consumption Standby 0.2 A...
  • Page 11 Shut down your equipment immediately if it produces smoke, a strange odor, or unusual noise. Continued use may lead to fire. Immediately unplug the equipment and contact your dealer or a Seiko Epson service center for advice. Never attempt to repair this product yourself. Improper repair work can be dangerous.
  • Page 12 Depending on the area, the interface cable may be included with the product. If so, use that cable. Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as Epson approved products by Seiko Epson Corporation.
