StudSensor
EDGE
™
Stud Finder
The Zircon StudSensor
EDGE stud finder finds
™
the edges of wood and metal studs up to 19 mm
deep in walls. It features a sleek, high-impact
case, with a patented pinch grip design, and a
new SpotLite
Pointer.
®
SpotLite
Pointer
®
Stud Edge Groove
Red EDGE Light
Green READY Light
Power Button
Battery Door Tab
StudSensor, SpotLite, and Zircon are trademarks or
registered trademarks of Zircon Corporation.
Advertisement
Related Manuals for Zircon StudSensor EDGE
Summary of Contents for Zircon StudSensor EDGE
- Page 1 SpotLite Pointer. ® SpotLite Pointer ® Stud Edge Groove Red EDGE Light Green READY Light Power Button Battery Door Tab StudSensor, SpotLite, and Zircon are trademarks or registered trademarks of Zircon Corporation.
- Page 2 1. INSTALLING THE BATTERY Do not attempt to unscrew the back of the tool. Push in the battery door tab at the bottom of the tool and open the door. Insert a new 9 V battery, matching the positive (+) and negative (-) terminals to the icons printed on the back.
- Page 3 After calibration is complete, continue to hold the Power button and slowly slide the unit across the surface. When the top red EDGE light is lit, the beep sounds, and the SpotLite ® Pointer arrow shines, you have located the edge of the stud.
-
Page 4: Operating Cautions
4. OPERATING CAUTIONS Depending on the proximity of electrical wiring or pipes to the wall surface, the StudSensor ™ EDGE may detect them in the same manner as studs. Caution should always be used when nailing, sawing, or drilling into walls, floors, and ceilings that may contain these items. - Page 5 Visit www.ZirconEurope.com for the most current instructions. LIMITED 2 YEAR WARRANTY any nature shall bind or obligate Zircon. Any implied warranties applicable to this product are limited to the Zircon Corporation, (“Zircon”) warrants this product to two year period following its purchase.
- Page 6 Separate collection. This product must not be disposed with normal household waste. Should your Zircon product need replacement or is of no further use to you, do not dispose of it with household waste. Make this product available for separate collection.
