Nitecore P26 User Manual

(English) P26 User Manual
Features
• Infinitely variable brightness tactical flashlight
• Utilizes a CREE XP-L HI V3 LED
• Max output up to 1000 lumens
• Integrated "Precision Digital Optics Technology" provides extremely good reflector
performance
• Boasts a peak beam intensity of 24000cd and a max throw of 310 meters
• Tail switch for tactical application
• Infinite brightness adjustment from 0.5 to 1000 lumens and a strobe mode
• High efficiency constant circuit provides unwavering output with runtime up to 500 hours
• Integrated impact resistance mechanism with reverse polarity protection
(Patent No.: 201220677948.7)
• Advanced Temperature Regulation module
• Integrated full metal tactical ring
• Two-way stainless steel titanium plated clip included
• Constructed from aero grade aluminum alloy with HAIII military grade hard-anodized finish
• Waterproof in accordance with IPX8 (two meters submersible)
• Impact resistant to 1.5 meters
• Tail stand capability
Dimensions
Length:
Head diameter:
Tail diameter:
Weight:
Accessories
Clip, lanyard, spare O ring×2, holster, spare tail cap, tactical ring
Battery Options
18650 Rechargeable Li-ion battery
Primary Lithium battery
Rechargeable Li-ion battery
Technical Parameters
FL1 STANDARD
NOTICE:
The above data has been measured in accordance with the international flashlight testing
standards ANSI/NEMA FL1 using 1×18650 Li-ion battery (3.7V 3500mAh). The data may vary
slightly during real-world use due to battery type, individual usage habits and environmental
factors.
* Infinite brightness adjustment varies from 0.5 to 1000 lumens and is manually adjustable
by rotation of the rotary switch. Subsequently, runtime will vary anywhere from 1 hour to 500
hours depending on chosen level of output (The runtime for Turbo mode is the testing result
before starting temperature regulation.)
149mm (5.87")
31.8mm (1.25")
25.4mm (1")
128.5g (4.53oz)
TURBO
1000 LUMENS
*1h
310m
24000cd
IPX8, 2m (Waterproof AND Submersible)
SIZE Nominal voltage
18650 3.7V
CR123 3V
RCR123 3.7V
ULTRALOW
0.5 LUMENS
*500h
7m
15cd
1.5m (Impact Resistant)
Compatible
Y (Recommended)
Y (Recommended)
Y
STROBE
1000 LUMENS
─
─
─
