Nitecore Smilodon P25 User Manual

ALL-ROUND Flashlight Expert
Features
Premium CREE XM-L U2 LED
·
Maximum output of 860 lumens
·
Integrated "Precision Digital Optics Technology" provides extreme
·
reflector performance
Boasts a peak beam intensity of 20,000cd and a throw distance of up to
·
283 meters
High efficiency circuit board provides up to 325 hours runtime
·
Integrated dual Picatinny connectors / rails provide a huge variety of
·
mounting options
Innovative single button two-stage switch offers a user-friendly interface
·
(patented)
Intelligent charging circuit with voltage detection charges safely and
·
rapidly
Integrated micro USB charging port is water, dust and impact resistant
·
Eight rapidly switchable brightness levels to select from
·
Integrated power indicator light displays remaining battery power
·
(patented)
Power indicator's secondary function displays battery voltage (accurate
·
to 0.1V)
Intelligent charging circuit with voltage detection charges rapidly and
·
safely
Intelligent memory function stores preferred brightness setting
·
Integrated spring-loaded impact absorption mechanism featuring
·
reverse polarity protection (patented)
Stainless steel titanium-plated two-way clip
·
Stainless steel retaining ring protects the core components from
·
damage
Toughened ultra-clear mineral glass with anti-reflective coating
·
Constructed from aero grade aluminum alloy
·
Sturdy HAIII military grade hard-anodized
·
Waterproof in accordance with IPX-8 (two meters submersible)
·
Impact resistant to 1.5 meters
·
Tail stand capability
·
Dimensions
Length: 160mm (6.3")
Head diameter: 40 mm (1.57")
Tube diameter: 25.4mm (1")
Weight 171g (6oz)(without battery)
Accessories
Quality holster, clip, tactical ring, lanyard, USB cable, spare tail cap and
spare O-ring
Battery Options
18650 Rechargeable Li-ion battery
Primary Lithium battery *
Rechargeable Li-ion battery *
*Warning: USB cable / charging function is for use with 18650
rechargeable li-ion batteries only. Do not attempt to
charge non-rechargeable batteries such as CR123 or
other types of rechargeable cells such as RCR123
batteries.
SIZE Nominal voltage Compatible
Yes (Compatible and
18650 3.7V
can be recharged)
Yes (Compatible but can
CR123 3V
NOT
be recharged)
Yes (Compatible but can
RCR123 3.7V
NOT
be recharged)
Thanks for purchasing NITECORE!
®
P25
Output & Runtime
TURBO
860
LUMENS
1 45
h min
1 15
h min
NOTICE
The above data has been measured in accordance with the international
flashlight testing standards ANSI/NEMA FL1 using one x 3.7V 2600mAh
Nitecore 18650 battery and 2 x 3V 1550mAh Nitecore CR123 batteries
under laboratory conditions. The data may vary slightly during real-world
use due to battery type, individual usage habits and environmental
factors.
NITECORE (SYSMAX) is a member of PLATO, participating in and
helping to develop the ANSI/NEMA FL1 standard of measurement.
Product testing data is in accordance with these internationally
recognized scientific standards.

Battery Installation

Insert one 18650 battery or two CR123 batteries with the positive pole
pointing forward (toward the light head).
Switching ON/OFF
To switch ON: Press the button on the tailcap until a "click" is heard.
To switch OFF: Press the button on the tailcap a second time until a
"click" is heard.
Momentary Illumination
Momentary illumination can be achieved by switching off the flashlight
and then half pressing and holding the tail switch. Release to turn the
light off.
User Manual
HIGH MID LOW
550 180 50
LUMENS LUMENS LUMENS
2 7 30
h
h
1 30 5 15 21
h min h min
283m
(Beam Distance)
20000cd
(Peak Beam Intensity)
1.5m
(Impact Resistant)
IPX-8, 2m
(Waterproof AND Submersible)
NOTE:
Ensure batteries are inserted with
the positive (+) end pointing to the
head. The P25 will not operate
with incorrectly inserted batteries.
LOWER
2
LUMENS
325
h h
200
h h
