  • Page 1 ® © Copyright 2011 ATEN International Co., Ltd. ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. This product is RoHS compliant. Part No. PAPE-1223-650G Printing Date: 04/2011 Patent No.

  • Page 2: Package Contents

    Package Contents 1 CS1768 8-Port USB DVI KVM Switch with Rack Mounting Kit 2 Custom USB DVI-D KVM Cable Sets 1 Firmware Upgrade Cable 1 Power Adapter 1 Grounding Wire 1 Foot Pad Set (4 pcs) 1 User Manual 1 Quick Start Guide...

  • Page 3: Single Stage Installation Diagram

    Stage Installation Manual Port Switching o set up your single stage CS1768 installation, refer to the installation diagram (the Use the front panel pushbutton switches to manu umbers in the diagrams correspond to the steps), and do the following: Plug your USB keyboard and USB mouse into the USB console ports located on the unit’s rear panel.
  • Page 4 CS1768 8-port USB DVI KVM Switch Quick Start Guide Requirements Console • A DVI compatible monitor capable of the highest possible resolution that you will be using on any computer in the installation • A VGA, SVGA, XGA, SXGA or multisync monitor capable of the highest resolution that you will be using on any computer in the installation •...

  • Page 5: Hardware Installation

    3. Slide the unit into the front or rear of the rack and secure it to the rack. Single Stage Installation To set up your single stage CS1768 installation, refer to the installation diagram (the numbers in the diagrams correspond to the steps), and do the following: 1.
  • Page 6 9. Turn on the power to the computers. Operation Port Selection The CS1768 provides three port selection methods to access the computers on the installation: Manual, an OSD (on-screen display) menu system, and Hotkeys. Manual Port Switching Use the front panel pushbutton switches to manually switch to a port.
  • Page 7 Performs a keyboard / mouse reset on the target computer. Enables/Disables the buzzer. [R] [Enter] Resets the hotkey settings to their default status. Invokes Video DynaSync, ATEN’s exclusive technology that eliminates boot-up display problems and optimizes resolution when switching between ports. Enables/Disables mouse emulation.

  • Page 8: Online Registration

    North America: http://www.aten-usa.com/product_ registration Technical Phone Support International: 886-2-86926959 North America: 1-888-999-ATEN Ext: 4988 United Kingdom: 44-8-4481-58923 The following contains information that relates to China: All information, documentation, and specifi cations contained in this media are subject to change without prior notifi...
