Canon imageFORMULA R10 Setup Manual

Setup Guide
Check the included items
There is no need to install any software
or scanner driver.
How to Scan
Connect the scanner and computer.
1
Open the feed tray to turn on the
2
scanner.
6T3-0114-01
USB cable
Press the release lever
while raising the feed tray
Start button lights up blue and
the scanner turns on.
3 Open the built in software  Align the document guides with both edges of
the loaded document.
(CaptureOnTouch Lite).
• A pop-up screen will be displayed with the software • Press the document beneath
icon. the tabs of the document guides.
Double-click the [CaptureOnTouch Lite
Setup Guide Launcher] icon.
Windows OS X
Check the included items
Tab
Click 6 Select the document type and scanned
Click
image storage location.
There is no need to install any software
or scanner driver. • Pressing the scanner start button does not start
CaptureOnTouch Lite.
If CaptureOnTouch Lite does not start, take the
following measures.
How to Scan
• Disconnect and reconnect the USB cable.
• If the scanner and computer are connected via a
Connect the scanner and computer.
1 USB hub, remove the USB hub and connect them
directly with a USB cable.
• Clicking allows you to change the scan type and
• Check whether access to USB devices is prohibited select a location to save your document.
by security software, and allow access if it is
• Clicking [New Document] allows you to add new
prohibited.
settings.
• In Windows, AutoPlay for USB memory devices
• Clicking [New output] allows you to add new storage
USB cable may be off. In that case, open Explorer and run the
locations.
[CaptureOnTouch Lite] icon in [Devices and drives].
2 Open the feed tray to turn on the Click the [SCAN] button.
4 Raise the document guides and feed 7
scanner.
extension plates.
Press the release lever
while raising the feed tray
Click
• When the software is open, you can also start
scanning with pressing the start button on the
scanner.
After confirming the scanned image,
8
click the [Finish] button.
5 Load the document.
 Turn the document upside down with the back
side facing you, and load it into the feed tray.
Click
Start button light up blue
6T3-0114-01 XXXXXXXX © CANON ELECTRONICS INC. 2020 PRINTED IN JAPAN
XXXXXXXX
9 Click [Open storage folder].
Click
Detailed Explanations
For detailed explanations on the scanner and CaptureOnTouch
Lite, refer to the user manual.
https://software.canon-elec.co.jp/ims/r10/
The user manual can also be displayed by double-clicking the
[manual] icon on the original pop-up screen. See of "How to
3
Scan".
Help
Technical support
USA
By internet: www.usa.canon.com/support
By phone: 1-800-423-2366
Canada
By internet: www.canon.ca/support
By phone: 1-800-OK-CANON (652-2666)
When the Software Update Notice
Screen Appears
Click the [Yes] button.
1
Click
The Web browser appears and downloading of the
update file begins.
Follow the instructions on the screen to
2
install the update.
Tips
● When scanning a card
Turn the card face up, and insert the card straight into
the card slot.
