INSIDE THE BOX
X7 Marauder, Warning card for battery installation, Holster, User manual.
SPECIFICATIONS
Material: AL6061-T6 aluminum alloy unibody design with MilSpec Type-Ⅲ
hard anodizing, along with blue bezel ring and stainless clamping
ring on the switch.
313 m
Turbo S
9000 lumens
Turbo S
9000
1800
2.5+200 8+215
MINS
*Four 18650 rechargeable lithium batteries with a bulging positive side and a
discharging current over 8A (up to 9000 lumens)
Four 18650 rechargeable lithium batteries with a bulging positive side and a
discharging current over 5A (up to 5500 lumens)
Stated data on Turbo and High mode has been measured indoor under 25
degrees Celsius, windless laboratory conditions. The data may vary due to
environmental and heat dissipation conditions
The specifications in the chart above claim to ANSI/NEMA FL1-2009 Standards
AVAILABLE BATTERIES
• 4 x 18650 Lithium BATTERIES
USER MANUAL
X7 Marauder
1 m
Turbo
5500 lumens
Turbo
High
5500
3000
1800
1800
32+200
MINS
MINS
24,500 cd
(L)127 x (D)68 mm
Medium
1000
6.5
HRS
IPX8
3*Cree XHP70
472 g
Excluding batteries
Low
Nightlight
300
18
HRS
Note: The two columns on
the tailcap must be inserted
into the empty spaces in the
battery compartment before
being screwed back on.
3
30
DAYS
Advertisement
Related Manuals for OLIGHT X7 Marauder
Summary of Contents for OLIGHT X7 Marauder
- Page 1 USER MANUAL X7 Marauder INSIDE THE BOX X7 Marauder, Warning card for battery installation, Holster, User manual. SPECIFICATIONS Material: AL6061-T6 aluminum alloy unibody design with MilSpec Type-Ⅲ hard anodizing, along with blue bezel ring and stainless clamping ring on the switch.
- Page 2 （EN）English BATTERY INSTALLATION Unscrew the tailcap counterclockwise and insert the four 18650 batteries according to the polarity symbols marked on the battery compartment and tailcap. Screw the tailcap back on tightly in a clockwise direction. The two columns on the tailcap must be inserted into the empty spaces in the battery compartment before being screwed back on.
- Page 3 Do not turn the light directly into human eyes. This may cause blindness for seconds or hurt the eyes. - Before your first use, please remove the protective film on the lens. - Do not use the Turbo S mode continuously when the environmental temperature is high in case the flashlight body is too hot to hold.
- Page 4 WARRANTY Within 30 days of purchase: Return to retailer from which you purchased for repair or replacement. Within 5 years of purchase: Return to Olight for repair or replacement. This warranty does not cover normal wear and tear, modifications, misuse, disintegrations, negligence, accidents, improper maintenance, or repair by anyone other than an Authorized retailer or Olight itself.
