Getting Started Guide
SCENE CONTROLLER SWITCH
2
GEN
ND
Cat. No. D2SCS
DI-000-D2SCS-02B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D2SCS and is the answer not in the manual?

Questions and answers

Related Manuals for Leviton D2SCS

Summary of Contents for Leviton D2SCS

  • Page 1 Getting Started Guide SCENE CONTROLLER SWITCH Cat. No. D2SCS DI-000-D2SCS-02B...
  • Page 2 Easy Wi-Fi lighting control for the whole home. See the complete line of My Leviton app compatible dimmers, switches, plug-ins, and controllers at: leviton.com/decorasmart...
  • Page 3 You can also use your voice with Amazon Alexa, Google Assistant, or Apple Siri — or use your smartphone or tablet with the My Leviton app, even when you are away from home. With three Scene control buttons and a built-...
  • Page 4 RF performance. • For indoor use only. Additional self-service support options can be found in the My Leviton app or at leviton.com/support RATINGS General Use 15A, 120VAC, 60Hz LED / CFL / Electronic Ballast 5A...
  • Page 5 At a Glance Scene Buttons • Configure the top three buttons via the My Leviton app to control other Decora Smart Wi-Fi devices, assign room scenes, create whole-house activities, and more. • Use the Apple Home app to set up control of HomeKit...

  • Page 6: Quick Tip

    • The bottom button (Switch) provides ON/OFF control and works with Alexa, Hey Google, and HomeKit/Apple Siri. • Use the My Leviton app to configure Scene buttons to: • Turn multiple Decora Smart Wi-Fi devices ON or OFF. • Have ON/OFF toggle control of an individual Decora Smart Wi-Fi device.

  • Page 7: Before You Install

    A 2.4GHz Wi-Fi network with high-speed internet. An iOS (version 12.0 or later) or Android (version 8.0 or later) mobile device. NOTE: Make sure that Wi-Fi and Bluetooth are enabled on your mobile device. A My Leviton cloud account (set up through the My Leviton app).
  • Page 8 Identify Your Wires WARNING: TO AVOID FIRE, SHOCK, OR DEATH, TURN OFF POWER AT THE CIRCUIT BREAKER! Check your wall box: Remove the wallplate and disconnect the existing switch. Restore power. Carefully test wires with voltage tester to find the Line (Hot) wire. Turn OFF power at the circuit breaker.
  • Page 9 To Light To Light LOAD LOAD LINE LINE NEUTRAL NEUTRAL GROUND GROUND GROUND GROUND TRAVELER TRAVELER From From Branch Circuit Branch Circuit If your wall box contains a different wiring configuration, contact Leviton’s Technical Support team or consult an electrician.
  • Page 10 Test and Install Restore power. Status LED should flash GREEN to indicate that your Switch is receiving power and ready to be enrolled. Press the bottom button to turn the Switch ON and confirm load control. Turn OFF power at the circuit breaker before screwing in your Switch.
  • Page 11 Get the App To download the app, visit and select the link, or scan my.leviton.com the QR code below for your device.

  • Page 12: Device Setup

    HomeKit, or both. • For voice control with Amazon Alexa or Google Assistant, you will need to set up the Switch in the My Leviton app. • For voice control with Siri, you will need to connect your Switch to Apple HomeKit. See page 14 for instructions.
  • Page 13 Configure Your Three Scene Buttons Follow the My Leviton app prompts to set up your Scene buttons. You can edit your Scene button functions at any time by selecting your Scene Controller Switch in the device list and choosing Reconfigure Buttons.
  • Page 14 Hey Google Tap the Menu icon. Tap Integrations. Locate and select the desired service. Follow app instructions. Visit my.leviton.com for a complete list of compatible smart home products. Pair an Anywhere Companion Put the Anywhere Companion in Pairing mode by pressing the top rocker 5 times.

  • Page 15: Diagnostic Led

    Wi-Fi 2nd Gen Scene Controller Switch with Apple Siri. Diagnostic LED If your device is not connecting to My Leviton app or to HomeKit, the Status LED on the bottom button can be used as a diagnostic tool. Press bottom button for at least 2 seconds, but no more than 7 seconds, and release.

  • Page 16: Status Led

    Green/Red/ Alternating Identify feature is triggered from the Amber Blink My Leviton app. Setup Mode Hold bottom button down for 7 seconds until the Status LED turns AMBER. Release the button. The Status LED will flash GREEN, indicating that the Switch is now in Setup mode.
  • Page 17 Order Engraved Buttons You can order Custom Engraved Buttons directly from the My Leviton App. Select your Scene Controller Switch in the device list, choose “Order Engraved Buttons”, and follow the instructions. Custom Engraved Buttons are currently available to U.S. customers only.

  • Page 18: Factory Default Reset

    Wi-Fi network. Not connected to Wi-Fi: • If your device is set up in the My Leviton app, select it and then tap “Device Settings“. Then, select “Reconfigure Wireless” and follow the in-app prompts. How do I clean my device? •...

  • Page 19: Safety First

    FCC SUPPLIER’S DECLARATION OF CONFORMITY Model D2SCS – Scene Controller Switch is manufactured by Leviton Manufacturing Co., Inc. 201 N. Service Road, Melville, NY 11747. www.leviton.com This device complies with part 15 of the FCC Rules.
