Pelican 3315 Introduction

Cat. #3315
INTRODUCTION
This compact flashlight produces an ultra
bright light beam by using an LED powered
by (3) three AA 1.5V alkaline batteries. The
3315 flashlight is designed for easy use with
one hand operation. The 3315 flashlight body
is made of a high impact polymer alloy for the
most durable construction. The 3315 flashlight
is water resistant.
BATTERY INSTALLATION
1. Ensure that the battery door lock is set to
'Unlock'
2. Twist the tail cap counter-clockwise until it
stops and pull tail cap off of body.
3. Replace ALL batteries with fresh AA
batteries as per polarity marking.
4. Replace tail cap, turn clockwise until it
clicks, then turn the battery door lock to
'Lock'.
TO OPERATE
1. Depress switch to turn on.
2. Depress switch again to turn off.
GENERAL CARE AND MAINTENANCE
1. Clean o-ring with a soft clean cloth to insure
that sealing area is free of dirt that could
destroy the o-ring seal.
2. Apply a light coat of clear silicone grease on
the o-ring occasionally.
Model Type:
Technical File No.:
Standards:
Coding:
• This product is constructed from ABS and
Polycarbonate.
Do not expose to aggressive atmospheres or
substances known the adversely affect this material
(eg acidic liquids, gases or solvents).
• The equipment must only be fitted with: Duracell
MN1500, Panasonic
"AA" size cells.
• Old and new cells must not be mixed. Different brands
must not be mixed. Cells must only be replaced in a
non-hazardous area.
3315
IECEx
TRC13.0007X
IEC60079-0:2009,
IEC60079-11:2011,
IEC60079-28:2015
Ex ia op is IIC T4 Ga
Ex ia op is IIIC T130
AM-3PA, or Sanyo LR6 alkaline
®
o
C Da
®
