Swiss Garde 360 Presence Secondary
Edition 06-2021
Art.-Nr. 25458, 25459
Secondary presence detector 16 m, 360°
EN
Sekundär-Präsenzmelder 16 m, 360°
D
Détecteur de présence secondaire 16 m, 360°
F
Rilevatore di presenza secondario 16 m, 360°
I
Czujnik obecności o zasięgu drugorzędne 16 m, 360°
PL
Advertisement
Related Manuals for Niko Swiss Garde 360
Summary of Contents for Niko Swiss Garde 360
- Page 1 Swiss Garde 360 Presence Secondary Edition 06-2021 Art.-Nr. 25458, 25459 Secondary presence detector 16 m, 360° Rilevatore di presenza secondario 16 m, 360° Sekundär-Präsenzmelder 16 m, 360° Czujnik obecności o zasięgu drugorzędne 16 m, 360° Détecteur de présence secondaire 16 m, 360°...
- Page 2 max. Ø 16 m 360° 2,5 m 12 m 360° 3,0 m 14 m 3,5 m 16 m ca. 50% 4,0 m 16 m ca. 50% 5,0 m 16 m 6,0 m 16 m Ø Ø Ø INSTALLATIONSANLEITUNG >1m 1. Produktbeschreibung Der Melder erkennt Personenbewegungen und Personenanwesenheit mittels Passiv-Infrarot Sensor (PIR).
- Page 3 INSTALLATION INSTRUCTIONS 1. Product description The device detects the movements and the presence of persons using a passive infrared sensor (PIR). It reacts most sensitively to movements which are tangential to the monitored area (1a). Movements directly towards the detector have a reduced sensitivity of approx. -50% (1b). The switching duration is extended as long as movements (entire area 1d) or the presence of persons (presence area 1e) are detected.
- Page 4 * Erforderliche Fachkenntnisse für die Installation Für die Installation sind insbesondere folgende Fachkenntnisse erforderlich: Niko prepares its manuals with the greatest care and strives to make them as complete • die anzuwendenden „5 Sicherheitsregeln”: Freischalten; gegen Wiedereinschalten sichern; correct and up-to-date as possible. Nevertheless, some deficiencies may subsist. Niko Spannungsfreiheit feststellen;...
