Summary of Contents for Lenovo ideacentre 300 Series
- Page 1 ideacentre 300 Series Quick Start Guide...
-
Page 2: Connect The Keyboard And Mouse
Unpack Computer Keyboard* Mouse* Power cord Publications * Selected models only. NOTE: Some models may contain items not listed here. Connect the keyboard and mouse Connect the Ethernet cable... -
Page 3: Connect The Display
Connect the display Choose the right voltage Selected models are equipped with a voltage selection switch. You can find it at the rear of your computer. Models without a voltage selection switch control voltage automatically. If the electricity supply range is 100-127 V AC, set the switch to 115 V. If the electricity supply range is 200-240 V AC, set the switch to 230 V. Connect the power cable... -
Page 4: Turn On The Computer
Turn on the computer Connecting to the Internet To connect to the Internet, you’ll need a contract with an Internet Service Provider (ISP) and some hardware. IPSs and ISP offerings vary by country. Contact your ISP for offerings available in your country. Your computer is designed to support a wireless (selected models only) or wired network that connects your computer to other devices. Wired network connection For wired networks, connect one end of an Ethernet cable (purchased separately) to the Ethernet connector on your computer, and then connect the other end to the network router or broadband modem. Consult your ISP for detailed setup instructions. NOTE: Broadband modem and router installation procedures vary depending on the manufacturer. - Page 5 Front/Top view of the computer Hard disk drive indicator Memory card reader Power button USB 2.0 connectors (2) Optical Drive Headphone connector Optical drive eject button Microphone connector Selected models only. ATTENTION: Be sure not to block any air vents on the computer. Blocked air vents may cause thermal problems.
-
Page 6: Rear View Of The Computer
Rear view of the computer 300-20IBR HDMI connector Wi-Fi antenna On-board VGA connector Power connector USB 3.0 connectors Cable clip Ethernet connector Expansion card slots Audio connectors Selected models only. Some models are equipped with USB 3.0 or TV tuner card. NOTE: If your model has two VGA monitor connectors, be sure to use the connector on the graphics adapter. ATTENTION: Do not open the Wi-Fi antenna cover. - Page 7 Rear view of the computer 300-20ISH Power connector USB 2.0 connectors Voltage selection switch Ethernet connector HDMI connector Wi-Fi antenna On-board VGA connector Audio connectors USB 3.0 connectors Expansion card slots Selected models only. Some models are equipped with USB 3.0 or TV tuner card. NOTE: If your model has two VGA monitor connectors, be sure to use the connector on the graphics adapter. ATTENTION: Do not open the Wi-Fi antenna cover.
-
Page 8: Windows Help System
The following information describes the technical support that is available for your product, during the warranty period or throughout the life of your product. Refer to the Lenovo Limited Warranty for a full explanation of Lenovo warranty terms. See “Lenovo Limited Warranty notice” later in this document for details on accessing the full warranty. If you purchased Lenovo services, refer to the following terms and conditions for detailed information: – For Lenovo Warranty Service Upgrades or Extensions,... -
Page 9: Replacing Or Upgrading Hardware
If you no longer have this copy of the Safety, Warranty, Environment, Recycling Information Guide and Important Product Information Guide, you can obtain one online from the website at http://www.lenovo.com/UserManuals. Pre-disassembly instructions Before proceeding with the disassembly procedure, make sure that you do the following: 1. - Page 10 Replacing or upgrading hardware Removing the computer cover Removing the front bezel...
- Page 11 Replacing or upgrading hardware Replacing a hard disk drive Replacing an optical drive...
- Page 12 Replacing or upgrading hardware Replacing the card reader module Replacing a PCI express adapter...
- Page 13 Replacing or upgrading hardware Replacing a memory module...
-
Page 14: Accessing Other Manuals
To access this guide, do the following: 1. Open the Start menu and then click or tap Lenovo Companion. If Lenovo Companion is not displayed on the Start menu, click or tap All apps to display all programs, and then click or tap Lenovo Companion. 2. Click or tap Support → User Guide. Models without preinstalled operating systems and Virtual Desktop Infrastructure (VDI) clients: Go to the Lenovo Support Web site to access your manuals. See “Downloading...
