Lenovo IdeaCentre AIO, 24ARR9, 27ARR9, 24IRH9, 27IRH9 Manual

About this documentation

  • This guide applies to the Lenovo product models listed below. Illustrations in this guide may look slightly different from your product model.
Model name Machine types (MT)
IdeaCentre AIO 24ARR9 F0HR
IdeaCentre AIO 27ARR9 F0HQ
IdeaCentre AIO 24IRH9 F0HN
IdeaCentre AIO 27IRH9 F0HM
  • Depending on the model, some optional accessories, features, and software programs might not be available on your computer.
  • Depending on the version of the operating systems and programs, some user interface instructions might not be applicable to your computer.
  • Documentation content is subject to change without notice. Lenovo makes constant improvements to the documentation of your computer, including this User Guide.
  • Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update. As a result, some information in this documentation might become outdated. Refer to Microsoft resources for the latest information.

Meet your computer

Overview

Meet your computer - Overview

Item Description Item Description
1 Microphones 2 Integrated camera activity indicator
3 Infrared LED* 4 Integrated camera
5 Infrared camera* 6 Multi-touch screen*
7 Air vent 8 Camera switch
9 Power button indicator 10 Power button
11 Wireless charging pad* 12 Wireless charging indicator*
13 Combo audio jack 14 USB-C® (3.2 Gen 2) connector

* for selected models

warning Note: Place the phone horizontally on the center of the wireless charging pad to activate wireless charging.

Statement on USB transfer rate

Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device.

USB device Data rate (Gbit/s)
3.2 Gen 1 5
3.2 Gen 2 10
3.2 Gen 2 × 2 20
Thunderbolt 3 40
Thunderbolt 4 40

Power indicator

Show the system status of your computer.

  • On: The computer is on.
  • Off: The computer is off or in hibernation mode.
  • Blinking slowly: The computer is in sleep mode.
  • "Use the touch screen (for selected models)".
  • "USB specifications".

Rear

Meet your computer - Rear

Item Description Item Description
1 HDMI™ in connector 2 Power connector
3 USB-A 2.0 connectors 4 Ethernet connector
5 USB-A 3.2 Gen 2 connector 6 HDMI 2.1 TMDS out connector
  • "USB specifications".

Specifications

Specification Description
Hardware To view the hardware information of your computer, type device manager in the Windows search box and then press Enter.
Power supply
  • 90-watt automatic voltage-sensing power supply*
  • 135-watt automatic voltage-sensing power supply*
Electrical input
  • Input voltage: From 100 V ac to 240 V ac
  • Input frequency: 50/60 Hz
Microprocessor To view the microprocessor information of your computer, type system information in the Windows search box and then press Enter.
Memory Double data rate 5 (DDR5) small outline dual in-line memory module (SODIMM)
Storage device
  • M.2 solid-state drive (SSD)

To view the storage drive capacity of your computer, type Disk Management in the Windows search box and then press Enter.

warning Note: The storage drive capacity indicated by the system is less than the nominal capacity.
Video features Maximum resolution:
  • HDMI out connector: 4096 × 2160 pixels, 60Hz
  • HDMI in connector:
    • FHD: 1920 x 1080 pixels, 100 Hz
    • QHD: 2560 x 1440 pixels, 100 Hz
Expansion M.2 slot × 2 (1 for Wireless LAN card, 1 for SSD)
Network features
  • Bluetooth
  • Ethernet LAN (Maximum speed: 1000 Mbit/s)
  • Wireless LAN

* for selected models

Operating environment

Maximum altitude (without pressurization)

  • Operating: From 0 m (0 ft) to 3048 m (10 000 ft)
  • Storage: From 0 m (0 ft) to 12192 m (40 000 ft)

Temperature

  • Operating: From 5°C (41°F) to 35°C (95°F)
  • Storage:
    • For common desktop computers: From -40°C (-40°F) to 60°C (140°F)
    • For all-in-one desktop computers: From -20°C (-4°F) to 60°C (140°F)

Relative humidity

  • Operating: 20%-80% (non-condensing)
  • Storage: 10%-90% (non-condensing)

USB specifications

warning Note: Depending on the model, some USB connectors might not be available on your computer.

Connector name Description
  • USB-A 2.0 connector
  • USB-A 3.2 Gen 2 connector
 Connect USB-compatible devices, such as a USB keyboard, USB mouse, USB storage device, or USB printer.
  • USB-C (3.2 Gen 2) connector
  • Charge USB-C compatible devices with the output voltage and current of 5 V and 3 A.
  • Connect to USB-C accessories to help expand your computer functionality. To purchase USB-C accessories, go to https://www.lenovo.com/accessories.

Get started with your computer

Access networks

This section helps you connect to a wireless or wired network.

Connect to Wi-Fi networks

Click the network icon on the bottom right of your display to connect to an available network. Provide required information, if needed.

warning Note: The wireless LAN module on your computer may support different standards. For some countries or regions, use of 802.11ax may be disabled according to local regulations.

Connect to the wired Ethernet

Connect your computer to a local network through the Ethernet connector on your computer with an Ethernet cable.

Adjust the computer stand

Connect an external display

Connect a projector or a monitor to your computer to give presentations or expand your workspace.

Change display settings

  1. Right-click a blank area on the desktop and select display settings.
  2. Select the display that you want to configure and change display settings of your preference.

Use the touch screen (for selected models)

For computers with a touch-enabled screen, you can touch the screen directly with your fingers and interact with computer in a simple way. The following sections introduce frequently used touch gestures.

warning Notes:

  • Some gestures might not be available when you are using certain apps.
  • Do not use gloved fingers or incompatible pens for input on the screen. Otherwise, the touch screen might be not sensitive or does not respond.
  • The touch screen is delicate. Do not apply pressure on the screen or touch the screen with anything hard or sharp. Otherwise, the touch panel might malfunction or get damaged.

One finger touch gesture

To do this Gesture
Open a shortcut menu. Tap and hold.
Open the widget panel. Swipe from the left.
Open notification center. Swipe from the right.

Two-finger touch gesture

To do this Gesture
Zoom out. Move two fingers towards.
Zoom in. Spread two fingers apart.

Three- and four-finger touch gesture

To do this Gesture
Show all open windows. Swipe with three fingers up.
Show the desktop. Swipe with three fingers down.
Switch apps. Swipe with three fingers to the left or right.
Switch desktops. Swipe with four fingers to the left or right.

To enable three- and four-finger touch gestures, do the following:
Step 1. Type touch gesture in the Windows search box and then press Enter.
Step 2. Turn on the Three- and four-finger touch gestures switch.

warning Notes: If the touch screen is not sensitive or does not respond, do the following:

  1. Turn off the computer.
  2. Use a dry, soft, and lint-free cloth or a piece of absorbent cotton to remove fingerprints or dust from the touch screen. Do not apply solvents to the cloth.
  3. Restart the computer and check if the touch screen works normally.
  4. If the touch screen cannot work normally, type Windows Update in the Windows search box and then press Enter.
  5. Follow the on-screen instructions to update Windows.
  6. After updating Windows, check if the touch screen works normally.
  7. If the touch screen still cannot work normally, the touch screen might get damaged. You can call Lenovo Customer Support Center to get further help.

Face authentication (for selected models)

Create your face ID and unlock your computer by scanning your face:

  1. Type Sign-in options in the Windows search box and then press Enter.
  2. Select the face ID setting and then follow the on-screen instruction to create your face ID.

The Vantage app

The Vantage app is a customized one-stop solution to help you maintain your computer with automated updates and fixes, configure hardware settings, and get personalized support.

To access the Vantage app, type Vantage in the Windows search box.

warning Notes:

  • The available features vary depending on the computer model.
  • The Vantage app makes periodic updates of the features to keep improving your experience with your computer. The description of features might be different from that on your actual user interface. You can download the latest version of Vantage app from Microsoft Store.

The Vantage app enables you to:

  • Know the device status easily and customize device settings.
  • Download and install UEFI BIOS, firmware, and driver to keep your computer up-to-date.
  • Monitor your computer health, and secure your computer against outside threats.
  • Scan your computer hardware and diagnose hardware problems.
  • Look up warranty status (online).
  • Access User Guide and helpful articles.

Connect to a Bluetooth device

You can connect all types of Bluetooth-enabled devices to your computer, such as a keyboard, a mouse, a smartphone, or speakers. To ensure successful connection, place the devices at most 10 meters (33 feet) from the computer.

Conventional pair

This topic helps you connect to a Bluetooth device by conventional pair.

Step 1. Type Bluetooth in the Windows search box and then press Enter.
Step 2. Turn on both the Bluetooth on your computer and the Bluetooth device. Make sure the device is discoverable.
Step 3. Select the device when it is displayed on the Add a device list, and then follow the on-screen instructions.

warning Notes: If the Bluetooth connection failed, do the following:

  1. Type Device Manager in the Windows search box and then press Enter.
  2. Locate the Bluetooth adapter. Right-click and select Update driver.
  3. Select Search automatically for drivers, and then follow the on-screen instructions.

Swift pair

This topic helps you connect to a Bluetooth device by swift pair.

If your Bluetooth device supports swift pair, do the following:

Step 1. Enable swift pair notification on Bluetooth settings page.
Step 2. Turn on both the Bluetooth on your computer and the Bluetooth device. Make sure the device is discoverable.
Step 3. Click Connect when a swift pair notification appears on your computer.

warning Notes: If the Bluetooth connection failed, do the following:

  1. Type Device Manager in the Windows search box and then press Enter.
  2. Locate the Bluetooth adapter. Right-click and select Update driver.
  3. Select Search automatically for drivers, and then follow the on-screen instructions.

Set the power plan

For ENERGY STAR® compliant computers, the following power plan takes effect when your computers have been idle for a specified duration:

  • Turn off the display: After 10 minutes
  • Put the computer to sleep: After 10 minutes

To awaken the computer from Sleep mode, press any key on your keyboard.

To reset the power plan:

  1. Type Power Options in the Windows search box and then press Enter.
  2. Choose or customize a power plan of your preference.

Off mode

To meet the off mode requirement of ErP/KES compliance, you need to disable the Fast Startup function. Please see details below.

  1. Go to Control Panel and view by Large or Small icons.
  2. Click Power Options ➙ Choose what the power buttons do ➙ Change settings that are currently unavailable.
  3. Clear the Turn on fast startup (recommended) option from the Shutdown settings ➙ Save changes.

Use software security solutions

The following software solutions help secure your computer and information.

  • Windows Security
    Windows Security is a software built-in to the operating system. It continually scans for malicious software, viruses, and other security threats. Besides, Windows updates are downloaded automatically to help keep your computer safe. Windows Security also enables you to manage tools including firewall, account protection, application and browser control, and so on.
  • Antivirus programs
    Lenovo preinstalls a full-version antivirus software on selected models of computer. It helps defend the computer against viruses, safeguard your identity, and keep your personal information secured.
  • Absolute Persistence
    Absolute Persistence technology is embedded in firmware. It detects changes that happen on the hardware, software, or the call-in location. It keeps you always knowing what condition the computer is in. To activate the technology, you have to purchase a subscription to Absolute.

warning Note: For more information about how to use these software solutions, refer to their help systems respectively.

CRU replacement

Customer Replaceable Units (CRUs) are parts that can be replaced by the customer. Lenovo computers contain the following types of CRUs:

  • Self-service CRUs: Refer to parts that can be replaced easily by customer themselves or by trained service technicians at an additional cost.
  • Optional-service CRUs: Refer to parts that can be replaced by customers with a greater skill level. Trained service technicians can also provide service to replace the parts under the type of warranty designated for the customer's machine.

If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU; and (2) you might be charged for the replacement CRU if Lenovo does not receive the defective CRU within thirty (30) days of your receipt of the replacement CRU. For full details, see the Lenovo Limited Warranty documentation at: https://www.lenovo.com/warranty/llw_02

CRU list

The following is the CRU list of your computer.

Self-service CRUs

  • ac power adapter
  • Keyboard
  • Mouse
  • Power cord

Remove or replace a CRU

This section provides instructions on how to remove or replace a CRU.

Power cord and ac power adapter

Prerequisite
Before you start, read Generic Safety and Compliance Notices, and print the following instructions.

warning Note: Do not remove the power cord when the computer is connected to ac power. Otherwise, there might be a risk of short circuits.

Removal steps

  1. Turn off the computer and remove all connected devices and cables.
  2. Remove the ac power adapter from the computer.
  3. Remove the power cord from the ac power adapter.
    Remove or replace a CRU - Removal steps

Help and support

Find your serial number

This topic helps you find computer serial number.

You can find your serial number via:

  • Dashboard or Device in the Vantage app
  • Serial number and machine type label of your computer (shown as below illustration)
    Your serial number

Diagnose and troubleshoot your computer

This section provides introduction to a set of diagnostics and troubleshooting tools at Lenovo Support Web site and the Vantage app. They can help you diagnose common software and hardware issues.

The following table lists these diagnostics tools and the recommended conditions for each tool.

Diagnostics tool Recommended scenario
Troubleshoot and diagnose at Lenovo Support Web site You want to have an online troubleshooting or scan of hardware and drivers on your computer.
Hardware scan
  • Your computer is installed with the Vantage app.
  • You want to perform basic examinations of the hardware components.

Troubleshoot and diagnose at Lenovo Support Web site

Lenovo provides two different diagnosing solutions to help you identify and resolve problems on your computer.

Step 1. Go to https://www.pcsupport.lenovo.com/ and enter your product name in the search box.
Step 2. Click Troubleshoot & Diagnose and select the option that fits your need.

warning Notes:

  • Before launching any automatic diagnosing process, a pop-up window will be prompted to install Lenovo Service Bridge. Lenovo Service Bridge helps to connect your computer with Lenovo diagnosing tools.
  • Lenovo Support Web site makes periodic updates of the sections to keep improving your experience with your computer. The Web site interface and descriptions of sections might be different from that on your actual interface.
  • If you are unaware of what problem your computer goes with, it is recommended that you select Easy and follow on-screen instructions to get your firmware updated and obtain the hardware status.
  • If you have identified the problem on your computer, you can select Custom and follow on-screen instructions to resolve the problem.

If solutions can not resolve problems on your computer, you can follow on-screen instructions to submit an e-ticket or contact Lenovo for professional assistance.

Hardware scan

Hardware scan is an effective hardware testing tool to help you identify existing hardware issues.

To run the Hardware scan:

Step 1. Type Vantage in the Windows search box and then press Enter.
Step 2. Click Hardware scan or Support ➙ Hardware scan.
Step 3. Select QUICK SCAN or CUSTOMIZE and then follow the on-screen instructions to run the hardware scan.
warning Notes:

  • The Quick Scan tool contains a pre-selected suite of tests that performs basic examinations of the hardware components found in the system. The Customize tool enables you to select one or several hardware components to perform the examinations.
  • Before selecting QUICK SCAN, click Refresh Modules to ensure that the list of hardware components are the components currently available for the computer.

Step 4. If any hardware failure is detected, the result varies depending on the warranty status and varies by country or region. Follow the on-screen instructions to resolve the issue.

Recovery

Use the following recovery options to reset or restore your computer when your computer comes with issues.

  • Use Lenovo recovery options.
    1. Go to https://support.lenovo.com/HowToCreateLenovoRecovery.
    2. Follow the on-screen instructions.
  • Use Windows recovery options.
    1. Go to https://pcsupport.lenovo.com.
    2. Detect your computer or manually select your computer model.
    3. Navigate to the troubleshooting menu to diagnose the operating system for recovery instructions.

Call Lenovo

If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center.

Before you contact Lenovo

Prepare the needed information before you contact Lenovo.

  1. Record the problem symptoms and details:
    • What is the problem? Is it continuous or intermittent?
    • Any error message or error code?
    • What operating system are you using? Which version?
    • Which software applications were running at the time of the problem?
    • Can the problem be reproduced? If so, how?
  2. Record the system information:
    • Product name
    • Machine type and serial number.

Self-help resources

Use the following self-help resources to learn more about the computer and troubleshoot problems.

Resources How to access?
Lenovo Support Web Site https://pcsupport.lenovo.com
Tips https://www.lenovo.com/tips
Lenovo Community https://forums.lenovo.com
Accessibility information https://www.lenovo.com/accessibility
Windows help information
  • Open the Start menu and click Get Help or Tips.
  • Use Windows Search or the Cortana® personal assistant.
  • Microsoft support Web site: https:// support.microsoft.com

Purchase accessories

Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your computer. Options include memory modules, storage devices, network cards, power adapters, keyboards, mice, and more.

To shop at Lenovo, go to https://www.lenovo.com/accessories.

Purchase additional services

During and after the warranty period, you can purchase additional services from Lenovo at: https://pcsupport.lenovo.com/warrantyupgrade
Service availability and service name might vary by country or region.

Documents / Resources

References

Download manual

Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.

Download Lenovo IdeaCentre AIO, 24ARR9, 27ARR9, 24IRH9, 27IRH9 Manual

Advertisement

Need help?

Need help?

Do you have a question about the IdeaCentre AIO and is the answer not in the manual?

Questions and answers

Related Manuals for Lenovo IdeaCentre AIO

Save Article as PDF

Table of Contents
