F3X23 Series
User Manual
F3X23 Series User Manual
The user manual is suitable for the following model:
Documentation No.
Product Name：
Model
Product Type
F3123
GPRS ROUTER
F3223
CDMA ROUTER
F3323
EDGE ROUTER
F3423
WCDMA ROUTER
F35223
TD-SCDMA ROUTER
F36323
EVDO ROUTER
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,China
Tel：+86 592-6300326 ，6300325，6300324
Fax:+86 592-5912735
http://www.fourfaith.com
Product Version
Zip Code:361008
Page
Total:
Advertisement
Table of Contents
Related Manuals for Four-Faith F3 23 Series
Summary of Contents for Four-Faith F3 23 Series
- Page 1 The user manual is suitable for the following model: Model Product Type F3123 GPRS ROUTER F3223 CDMA ROUTER F3323 EDGE ROUTER F3423 WCDMA ROUTER F35223 TD-SCDMA ROUTER F36323 EVDO ROUTER Xiamen Four-Faith Communication Technology Co., Ltd. Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare Park,XiaMen,China Zip Code:361008 Tel：+86 592-6300326 ，6300325，6300324 Fax:+86 592-5912735 http://www.fourfaith.com...
- Page 2 User Manual Files Revised Record Date Version Remark Author Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 3: Copyright Notice
Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome. - Page 4 User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 5: Table Of Contents
3.3.15 L2TP Client ......................30 3.3.16 IPSEC Client ......................32 3.3.17 Dynamic DNS ...................... 32 3.3.18 Serial Settings ...................... 34 Chapter 4 Appendix ........................36 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... -
Page 6: Chapter 1 Brief Introduction Of Product
Support auto recovery mechanism, including online detect, auto redial when offline to make router always online Ethernet port: 1.5KV magnetic isolation protection RS232/RS485/RS422 port: 15KV ESD protection SIM/UIM port: 15KV ESD protection Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... -
Page 7: Working Principle
1.4 Specifications Cellular Specification Standard and Band Bandwidth TX power sensitivity F3123 GPRS ROUTER 85.6Kbps GSM850/900： <-107 EGSM900/GSM1800MHz, Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... - Page 8 32MB(Extendable to 64MB) Interface Type Item Content Ethernet 1 10/100 Mbps Ethernet port(RJ45), auto MDI/MDIX, 1.5KV magnetic isolation protection Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
- Page 9 Operating -25~+65º C（-13~+149℉） Temperature Extended -30~+75º C（-22~+167℉） Operating Temperature Storage -40~+85º C（-40~+185℉） Temperature Operating 95% ( Non-condensing) Humidity Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
-
Page 10: Chapter 2 Installation Introduction
Power adapter Manual CD Certification card Maintenance card Stator optional 2.3 Installation and Cable Connection : (unit: mm) Dimension Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735... -
Page 11: Installation Of Antenna
Insert one end of network direct cable into RJ45 outlet with sign “ETH” of the router, and insert the other end into the Ethernet interface of user’s device. The signal connection of network direct cable is as follows: RJ45-1 RJ45-2 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... -
Page 12: Power
We recommend user to use the standard DC 12V/1.5A power. 2.5 Indicator Lights Introduction The router provides five indicator lights: “Power”, “Online”, “Alarm”, “System”, “Link/ACT”. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... -
Page 13: Reset Button Introduction
The router has a “Reset” button to restore it to its original factory default settings. When user press the “Reset” button for up to 15s, the router will restore to its original factory default settings and restart automatically. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 14: Chapter 3 Configuration And Management
Ethernet port is 192.168.1.2). It will prompt a login page. The default username and password are both “admin”. Please input the username and password login to access the configuration pages. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 15: Configuration
The “Welcome” page will give some contact information, if you have any question or problem, please contact us. 3.3.2 WAN Settings This page is used to configure the Internet access parameters. WAN Wireless Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... - Page 16 You can also use your own DNS address. If you want to use your own DNS, please make sure the DNS address you configured is usable and stable. Keep Online Detection Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
-
Page 17: Lan Settings
Note: When you choose the “Route” or “Ping” method, it’s quite important to make sure that the “Primary Detection Server IP” and “Backup Detection Server IP” are usable and stable, because they have to response the detection packet frequently. 3.3.3 LAN Settings Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 18: Nat
Service Type: The protocol type of the target packet Outside Starting Port: The target packet’s destination port Inside Start Port: The destination port of packet which has been processed by the NAT module. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 19: Dmz
Instead of discarding traffic for services you have not defined, you can have it forwarded to one computer on your network. This computer is called the Default DMZ Server. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 20: Filter
Only Accept The Following--Accept all packets matched the custom filter rules, Discard all other packets Add Filter Item Direction input: packet from WAN to LAN Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... - Page 21 Address ,the filter item could be configured as following: The following is the configured filter item: MAC Restrict This filter function is based on the Ethernet MAC address. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
-
Page 22: Static Routes
VPN tunnel or multiple IP subnets located on your local network. Press “Add” button to start add a custom static route: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 22 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... -
Page 23: Router Status
This page displays the router’s status information. Account Name: The username to login the router. Firmware Version: Software version information Module Type: The wireless module used to get the Internet access Xiamen Four-Faith Communication Technology Co.,Ltd. Page 23 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... - Page 24 Interface: The interface name of the PPTP tunnel when the tunnel is up. Local Tunnel IP: The local tunnel IP Address when the tunnel is up. Remote Tunnel IP: the PPTP server’s tunnel IP Address when the tunnel is up. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 24 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
-
Page 25: Backup Settings
“Browse” button to browse to the file. When you have located it, click the “Restore” button to send the file to the router to restore configuration. 3.3.10 Load Default Xiamen Four-Faith Communication Technology Co.,Ltd. Page 25 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China... -
Page 26: Set Password
The default username and password are both “admin”. To change the username and password, type the new username, old password and new password. 3.3.12 Logs Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：... - Page 27 Log Way: there are three log ways Web: The log message is displayed on this web page. You can save the log message to a file by click “Save Log” button. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 27 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
- Page 28 None Stopbit: Flow control: None When you configure the serial port settings , press “call” button ,The router log message will be displayed. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 28 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
- Page 29 The log message is output to a syslog server, if choose this way, you should input a syslog server’s IP Address and run a syslog server program on it. . Xiamen Four-Faith Communication Technology Co.,Ltd. Page 29 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
-
Page 30: Misc
User Manual 3.3.13 Misc Normally, the four-faith web config tool listens on port 80. If you want to change listening port, please configure “web config port” item. To reboot the router , press the “Reboot” button. 3.3.14 PPTP Client Enable PPTP Client: Enable or disable PPTP Client function PPTP Server IP: The PPTP server’s IP Address... - Page 31 L2TP Server dynamically. You can also use the fixed local tunnel IP if the L2TP Server support User Name: Username to login the L2TP Server. Password: Password to login the L2TP Server. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 31 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
-
Page 32: Ipsec Client
DNS service, which will allow you to register your domain to their IP address, and will forward traffic directed at your domain to your frequently-changing IP address. The four-faith router currently support 88ip(www.88ip.net) and 3322(www.3322.org) Dynamic DNS provider. 88ip: Xiamen Four-Faith Communication Technology Co.,Ltd. - Page 33 Customer Domain: Your custom 3322 domain name. User Name: Your 3322 account username Password: Your 3322 account password Update Interval: The time interval of IP Address update. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 33 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
-
Page 34: Serial Settings
3.3.18 Serial Settings There is a console port on Four-Faith router. Normally, this port is used to debug the router. This port can also be used as a serial port. The router has embedded a serial to TCP program. The data sent to the serial port is encapsulated by TCP/IP protocol stack and then is sent to the destination server. - Page 35 Enable Serial TCP Function: Enable the serial to TCP function Protocol Type: The protocol type to transmit data. UDP(DTU) – Data transmit with UDP protocol , work as a Four-Faith DTU which has application protocol and hear beat mechanism. Pure UDP – Data transmit with standard UDP protocol.
-
Page 36: Chapter 4 Appendix
3. Choose the correct COM port which connects to modem, choose “OK” 4. Configure the serial port parameters as following, choose “OK” Bits per second: 115200 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 36 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com... - Page 37 Data bits: 8 Parity: None Stop bits: 1 Flow control: None 5. Complete Hyper Terminal operation, It runs as following Xiamen Four-Faith Communication Technology Co.,Ltd. Page 37 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
- Page 38 User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 38 of 38 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
