Midland G5 XT Manual

MIDLAND G5 XT
PMR446 transceiver
Thanks for choosing Midland! Midland G5XT is a portable
transceiver that is free use in almost all European countries. For
further information, we suggest you look at the "Restrictions on the
use" chart.
Combining the latest technology in radio communication along with a
sturdy mechanical frame, the Midland G5XT makes the ideal and effective
solution for the professionals who need to stay in touch with colleagues
(construction sites, buildings, hotels, trade fairs, shows) or with leisure
users that just want to keep up with friends and family.
Its robust frame and the simple design make it ideal for any activity.
CONTENT
•
2 MIDLAND G5 XT transceiver
• 6 Ni-MH rechargeable batteries
•
2 belt clips
•
2 wall chargers
COVERAGE/RANGE
The maximum range depends on terrain condition and is obtained during
use in an open spaces.
The only limitations to maximum possible range are environmental factors
such as blockage caused by trees, buildings, or other obstructions. Inside
a car or a metallic construction, the range can be reduced.
Normally the coverage in the city, with buildings or other obstructions is
about 1 or 2 Km. In open spaces but with obstructions like trees, leaves
or houses the maximum possible range is about 4-6 Km. In open spaces,
without obstructions and in sight, like for example in mountain, the
coverage can be more than 12 Km.
DESCRIPTION OF THE CONTROLS
AND FUNCTIONS
DISPLAY
Your midland G5XT keeps you constantly updated about its operational
status through a Liquid Crystal Display (LCD). The symbols and their
corresponding parameters that may appear, according to the operational
status of the device, are described as follows:
TX Appears while you are transmitting a signal (PTT button
pressed)
RX Means that the radio is receiving a signal.
Indicates the channel selected
Indicates the sub audio tone selected. (of-38).
VOX Indicates if VOX MODE is active.
Indicates the battery level.
Indicates if the Out of Range is active.
Indicates that the baby sitting function is on.
DESCRIPTION OF THE CONTROLS
Refer to this picture to identify the various parts of the device:
ANTENNA
BUILT-IN SPEAKER - Here is where the
speaker is housed.
BUILT-IN MICROPHONE - Here is where
sound is picked up by the microphone.
PTT (push to talk) Push this button to transmit.
▲▼ use these buttons for changing the
settings
/ - Pressing this button you can use the
Out of range function. If you keep it pressed for
about 5 seconds, the keypad lock is activated.
MODE/ - Press this button to enter the
radio's menu. If you keep it pressed for about 3
seconds, you turn on/turn off the radio.
