Asus CW100 Manual

A
Model:
Hardware Version:
Software Version:
UKCA RF Output table (The Radio Equipment Regulations 2017)
Max Output Power (EIRP): Mouse: 0 dBm
Operating Frequency
Range:
CE RED RF Output table (Directive 2014/53/EU)
Max Output Power (EIRP): Mouse: 0 dBm
Operating Frequency
Range:
Frequency Deviation:
Modulation Type:
Mouse Resolution:
Battery:
Power Rated:
Operation Distance:
Keyboard Dimension:
Mouse Dimension:
Dongle Dimension:
Operating Temperature:
Package contents:
CW100 Keyboard*1, CW100 Mouse*1, USB dongle*1 (stored inside the mouse), Quick Start Guide*1, Warranty
booklet*1, AAA Alkaline Battery*1, AA Alkaline Battery*1
B
Installing the batteries
1. Insert the batteries (one AAA battery for keyboard and one AA battery for mouse) into the battery slots of
your keyboard and mouse.
• The low battery indicator of the mouse is beneath the scroll wheel and that of the keyboard is above the numeric
keypad.
• Please replace the battery when the low battery indicator ashes red.
Wireless Keyboard and Mouse Set CW100
Mouse: CW100-M
Mouse: 0.6
Mouse: V3.4.9
Mouse:
2402 MHz - 2480 MHz
Mouse:
2402 MHz - 2480 MHz
+/- 50KHz
GFSK
800 / 1000 / 1200 DPI
Mouse - AA battery x1; Keyboard - AAA battery x1
1.5V (Keyboard) / 1.5V (Mouse) / 5V (Dongle)
Keyboard - 10M without signal disturbance and no direction limit
Mouse - 10M without signal disturbance and no direction limit
445.11mm x 133.21mm x 26.82mm; Weight: 489.5g (without battery)
112.55mm x 60.01mm x 36.77mm; Weight: 58.8g (without battery)
19.52mm x 15.70mm x 6.5mm; Weight: 1.9g
+5˚C ~ +40˚C
Keyboard: CW100
Keyboard: 1.0
Keyboard: 1.0.3
Keyboard: 0 dBm
Keyboard:
2404 MHz - 2478 MHz
Keyboard: 0 dBm
Keyboard:
2404 MHz - 2478 MHz
+/- 50KHz
Storage Temperature: -20˚C ~ +55˚C
Wireless Receiver: CW100-D
Wireless Receiver: VER01
Wireless Receiver: 1.96E
Wireless Receiver: 0 dBm
Wireless Receiver: 2402-2480 MHz
Wireless Receiver: 0 dBm
Wireless Receiver: 2402-2480 MHz
+/- 50KHz
