CN8000A
Single Port KVM over IP
Quick Start Guide
© Copyright 2019 ATEN
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All
other trademarks are the property of their respective owners.
Part No. PAPE-1223-397G
®
International Co., Ltd.
Printing Date: 11/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CN8000A and is the answer not in the manual?

Questions and answers

Related Manuals for ATEN CN8000A

Summary of Contents for ATEN CN8000A

  • Page 1 Quick Start Guide © Copyright 2019 ATEN ® International Co., Ltd. ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. Part No. PAPE-1223-397G Printing Date: 11/2019...

  • Page 2: Package Contents

    Package Contents 1 CN8000A Single Port KVM over IP 1 Custom KVM Cable 1 Custom Console Cable 1 Laptop USB Cable 1 Power Adapter 1 Mounting Kit 1 User Instructions Overview Front View Rear View...
  • Page 3 Installation Rack Mounting DIN Rail Mounting Setup Serial Console Device (Router, Switch) Modem Modem PN0108 Cat 5e/6 Cable KVM Switch...

  • Page 4: Installation

    CN8000A Single Port KVM over IP Overview Front view LAN Port LUC (Laptop USB Console) Port Firmware Upgrade/Reset Switch 10/100/1000 Mbps LED Link LED Power LED Rear view Power Jack PC/KVM Port PS/2 – USB Console Port PON (Power Over the NET™) Port...
  • Page 5 DIN Rail Mounting To mount the CN8000A on a DIN rail: 1. Screw the mounting bracket to the back of the CN8000A as described in steps 1 and 2 of the Rack Mounting procedure. 2. Use the large screws supplied with the rack mount kit to screw the DIN rail brackets to the mounting brackets.

  • Page 6: Operation

    Browser To operate the CN8000A from a web browser, do the following: 1. Open a web browser and enter the IP address of the CN8000A you want to access. Note: The CN8000A’s default setting is for DHCP but if after one minute it fails to fi nd a DHCP server, it will use the default IP Address: 192.168.0.60...

  • Page 7: Mouse Setup

    Password: password. For security purposes, we strongly recommend that you change the default username and password. 3. After you have successfully logged in, the CN8000A Main Screen appears. 4. To access the computer, click the Viewer icon in the left column near the bottom.

  • Page 8: Emc Information

    Important. Before proceeding, download the Installation and Operation Manual by visiting the website, www.aten.com and navigating to the product page. The manual includes important warnings, loading specifi cations and grounding instructions.
