Aeotec AEOEZW141 Quick Start Manual

Aeotec
AEOTEC - Nano Shutter
SKU: AEOEZW141
Quickstart
This is a secure Roller Shutter for Europe. To run this device please connect it to your mains power supply.
n s t y o u r n o u t t
S
1 . a l l a h
I N
n t o o n
S c a h e Q R c d e
2 .
o w r n y o u r n o
P
3 . e a
O N
o u r n o u t t r w
Y S
4 . a h e
N
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,
distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this
equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-
Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
Aeon Labs Nano Shutter is a Z-Wave power binary switch device based on Z-Wave enhanced 232 slave library V6.71.01. Its surface has a pin socket, which can
be used for connecting to the touch panel, so you can also use the touch panel to control the Nano Shutter. It can also be included and operated in any Z-Wave
network with other Z-Wave certified devices from other manufacturers and/or other applications. All non-battery operated nodes within the network will act as
repeaters regardless of the vendor to increase the reliability of the network. It is a security Z-Wave plus device, so a security-enabled controller is needed to take
full advantage of all functionally for the Nano Shutter. It also supports the Over The Air (OTA) feature for the product?s firmware upgrade. As soon as Nano Shutter
is removed from a Z-Wave network it will be restored into default factory setting.
NEW: This device supports Smart Start and Positioning as well as Venetian -Mode
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do
this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended
to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
Press the Action Button for 20 secounds
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the
assembly of the product, the voltage network has to be switched off and ensured against re-switching.
Installation
manual.zwave.eu/backend/make.php?lang=en&sku=AEOEZW141
r
e
.
n o u t t r u s n y o u r v
a S h e i g Z W a e g a
-
N
u t t r
S
h e
u t o m t y p r t o y o u r v
Z W
i l l a a i c a l l a i a
-
t w y o n t r o r s p p
e a c l l e a
/ .
n t w o r
e e k
.
