Aeotec NanoMote One Operating Manual

Hide thumbs

Advertisement

Table of Contents

OPERATING MANUAL
NanoMote One
ZWA004-A/C
NanoMote One is a wireless, portable and rechargeable product. On one hand, it can be used to
control separate Z-Wave device, such as a smart Plug, smart Dimmer, Bulb, etc. through Z-Wave
Gateway. On the other hand, it can also be used to program a scene by Gateway app which groups
many smart nodes such as Plugs, Bulbs, and Siren... The scene may refer to sleep scene, movie
scene and entertainment scene, etc. as you created.
Features:
1. Z-Wave Plus certified for good compatibility (500 serials chipset)
2. Z-Wave S2 system
3. Support remote control anywhere and anytime.
4. The battery is rechargeable, will run for three months per charge
5. Support low battery alarm with buzzer
6. Support Child Lock function
7. Supporting firmware OTA
Ⅰ. GENERAL INFORMATION ABOUT NanoMote One
1. Product layout

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NanoMote One and is the answer not in the manual?

Questions and answers

Related Manuals for Aeotec NanoMote One

Summary of Contents for Aeotec NanoMote One

  • Page 1 NanoMote One ZWA004-A/C NanoMote One is a wireless, portable and rechargeable product. On one hand, it can be used to control separate Z-Wave device, such as a smart Plug, smart Dimmer, Bulb, etc. through Z-Wave Gateway. On the other hand, it can also be used to program a scene by Gateway app which groups many smart nodes such as Plugs, Bulbs, and Siren...
  • Page 2 2. Specifications Power supply: 1 x LIR2450 3.6V Battery Storage environment: -10℃-50℃ 0%-85% Operational temperature: 0-40℃ Radio protocol: Z-Wave Radio frequency: 868.42MHz (EU) 908.42MHz (US) 921.42MHz (ANZ) Range: More than 100m outdoors About 30m indoors (depending on building materials) Dimensions: 50*50*14.5MM Working current: 36mA...
  • Page 3 Ⅱ. INSTALLATION Open the cover Insert battery and close the cover...
  • Page 4 Ⅲ. Z-WAVE NETWORK INCLUSION NanoMote One can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers and/or other applications. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.
  • Page 5 COMMAND_CLASS_SWITCH_MULTILEVEL VI. LOW BATTERY ALARM FUNCTION NanoMote One will send battery report to the lifeline group when button is triggered during the sleep mode. If the battery level of the NanoMote One is less than 20%, the NanoMote One will...

  • Page 6: Child Lock Function

    VII. WAKE UP Pressing and holding button for 5 seconds and then release so the NanoMote One will wake up itself and send wake-up notification out to Z-Wave Controller. After that, it can be operated to update parameters, OTA, and detect battery level etc.

  • Page 7: Battery Charging

    XI. BATTERY CHARGING NanoMote One has an internal rechargeable battery that will run for three mouths under the normal use condition. The charger's output should be a micro USB terminal with the specification of output DC 5V.The LED color is red during the charging process, and it will turn to green if the charging is finished.

  • Page 8: Button Function

    XIII. BUTTON FUNCTION NanoMote One offers three button action types, including short press, held down and release. Short press allows Scene Controller sends: Central scene notification commands to the nodes associated nodes.
  • Page 9 accessed from main controllers configuration interface. Parameter No.32 Level of low battery Available settings: 10-50 (10% - 50%) Default setting: 20 (20%) Parameter size: 1[byte] Parameter No.41 Enable send central scene notification. 0 - Disable. 1 – Enable. Default setting: 1 Parameter size: 1[byte] Parameter No.42 Setting the duration value of the command switch multilevel.
  • Page 10 against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
