Aeotec ZWA042 Manual

Outdoor smart plug

Advertisement

Quick Links

Outdoor Smart Plug
ZWA042
FCC
Federal Communications Commission (FCC) Statement FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the
equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This equipment should be
installed and operated with minimum distance 20cm between the radiator and your body.
WARNING
RISK OF FIRE
RISK OF ELECTRICAL SHOCK
RISK OF BURNS
CONTROLLING APPLIANCES:
EXERCISE EXTREME CAUTION WHEN USING Z-Wave™ DEVICES TO CONTROL APPLIANCES. OPERATION OF THE Z-Wave™ DEVICE MAY BE IN A DIFFERENT ROOM THAN THE CONTROLLED APPLIANCE, ALSO
ANUNINTENTIONAL ACTIVATION MAY OCCUR IF THE WRONG BUTTON ON THE REMOTE IS PRESSED. Z-Wave™ DEVICES MAY AUTOMATICALLY BE POWERED ON DUE TO TIMED EVENT PROGRAMMING. DEPENDING UPON
THE APPLIANCE, THESE UNATTENDED OR UNINTENTIONAL OPERATIONS COULD POSSIBLY RESULT IN A HAZARDOUS CONDITION. FOR THESE REASONS, WE RECOMMEND DO NOT RETURN THIS PRODUCT TO THE STORE
THE FOLLOWING: DO NOT USE Z-Wave™ DEVICES TO CONTROL ELECTRIC HEATERS OR ANY OTHER APPLIANCES WHICH MAY PRESENT A HAZARDOUS CONDITION DUE TO UNATTENDED OR UNINTENTIONAL OR
AUTOMATIC POWER ON CONTROL.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZWA042 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aeotec ZWA042

  • Page 1 Outdoor Smart Plug ZWA042 ( ) Federal Communications Commission (FCC) Statement FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 ZWA042 User Manual Specifications ITEM INFORMATION Model ZWA042 Power Supply AC 120V 60HZ Signal(Frequency) 908.42MHz Range Up to 100 feet line of sight between the Wireless Controller and the closest Z-Wave™ receiver module. Operating Temperature Range 5-104° F (-10-40° C) Specifications subject to change without notice due to continuing product improvement Website:www.aeotec.com/...
  • Page 3 ZWA042 User Manual Support Association Group and Auto Report switch status Support firmware upgrades via Over-the-air (need Gateways support) Support SmartStart Product Overview A. on/off button B. Output Outlet C. Protector E. InPut...
  • Page 4: Button Definition

    ZWA042 User Manual Button & Indicator Function Description Button Definition ITEMS Action (time unit: second) Description Out of network: Z-Wave network inclusion(ADD) (send out NIF of full functionality ) Tap one time [0.04,1] In network: N/A In/Out of network: controls/toggles output on/off Out of network: N/A Tap two times [0.04, 1] In network: Z-Wave network exclusion(REMOVE: Send out NIF) .
  • Page 5 ZWA042 User Manual Action Press down Action Button Release Action Button Press and hold Pulses Blue Color slowly based on [22,∞) unpaired status. Adding Your Device To Hub The device support two methods of inclusion, When using a Z-Wave Plus™ certified controller choose Network Wide Inclusion or SmartStart. TAP the button once to ADD/INCLUDE the device.
  • Page 6 ZWA042 User Manual Command Class Endpoint ROOT CC List Command Class Name Version Required Security Class Z-Wave Plus Info none Security 2 none Supervision none Transport Service none Association highest granted Association Group Information highest granted Multi Channel Association highest granted Version highest granted Manufacturer Specific...
  • Page 7 ZWA042 User Manual Command Class Name Version Required Security Class Association highest granted Association Group Information highest granted Multi Channel Association highest granted Switch Binary highest granted Scene Activation highest granted Scene Actuator Configuration highest granted Notification highest granted Endpoint 2 CC List Command Class Name...
  • Page 8 ZWA042 User Manual Basic Set Mapping Basic CC is mapped to Switch Multilevel CC and Binary Switch CC as below: Basic Set Node Mapping ENDPOINT ROOT Binary Switch Set EP1 ENDPOINT 1 Binary Switch Set EP1 ENDPOINT 2 Multilevel Switch Set EP2 ## Indicator Command Class The indicator (blue color) will flashes according the indicator set command received from HUB.
  • Page 9 ZWA042 User Manual Name Node Count Profile Function Lifeline General: Lifeline Switch Binary Report Endpoint 2 Name Node Count Profile Function Switch Multilevel Report Lifeline General: Lifeline Switch Color Report Group mapping The endpoint 1 and 2's Lifeline Group are mapping to endpoint root's Lifeline.
  • Page 10: Configuration Parameters

    ZWA042 User Manual Configuration Parameters Read Number Name Information Format / Size Altering Advanced Default Value Description Only 0 - Disable LED completely 1 - Turn on between particular times only (Night Light Mode) 1 byte unsigned Reaction of led Parameter setting to change the reaction of LED setting.
  • Page 11 ZWA042 User Manual Read Number Name Information Format / Size Altering Advanced Default Value Description Only 0 - Can be disabled by 1x tapping switches action button once 1- Can be disabled by 2x tapping Switches action button within 1 second Alarm disable Determines the method of disabling the alarm of the 1 byte unsigned...
