Aeotec TriSensor AEOEZWA005 Manual

Aeotec
TriSensor
SKU: AEOEZWA005
ZWave+
Quickstart
This is a secure Notification Sensor for XXXQFrequencyName. To run this device please insert fresh 1 * CR123A batteries. To run this device please
make sure the internal battery is fully charged. Press once TriSensors Action Button. If it is the first installation, the yellow LED will keep solid until whole
network processing is complete. If successful, the LED will flash white -> green -> white -> green, after 2 seconds finished. If failed, the yellow LED lasts for
30 seconds, then the green LED flashes once.If it is the S2 encryption network, please enter the first 5 digits of DSK.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer,
importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other
material. Use this equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or
near open heat sources.
Product Description
TriSensor can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers and/or other applications. All
non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. If PIR motion sensor is
triggered, the TriSensor will send a Basic set to associated devices.The PIR motion sensor will then become inactive. If no PIR motion is triggered after the
PIR interval time (configurable), the TriSensor will send Basic Set to the associated nodes.
Installation
With your TriSensor now a part of your Z-Wave network and having determined its installation location, it s time to finish its
physical installation. There are 2 ways that your TriSensor can be mounted on a wall or ceiling. Most simply it can be placed upon
a shelf without the need to attach further accessories. You can mount your sensor in a corner or against a wall or ceiling by using
the Back-Mount Plate. It s also possible to embed your TriSensor within a ceiling or wall using its Recessor accessory (sold
separately).
To install your TriSensor:
Reattach the three parts of your TriSensor to each other. Unlock the Battery Cover from the Sensor unit.
You may also install your TriSensor on any flat surface area such as tables, and bookshelves;
You can place it upon a shelf without the need to attach further accessories.
To install your TriSensor with the Back-Mount Plate;
