Service Manual
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Published by Philips Consumer Lifestyle
12/08
TECHNICAL INFORMATION
- Voltage
- Frequency
- Power consumption
- Colour setting
- Contents
- SAP coding
OPTIONAL (accessories)
- Commercial trade number jug + juglid : HD7985/30 (Grey)
Printed in the Netherlands
Coffee maker Pure
HD7690/30
: 220 - 240 V
: 50 - 60 Hz
: 1400 W
: White/Steel
: 1200 cc
: HD7690/30
© Copyright reserved
Subject to modification
Advertisement
Related Manuals for Philips Pure HD7985/30
Summary of Contents for Philips Pure HD7985/30
- Page 1 - Contents : 1200 cc - SAP coding : HD7690/30 OPTIONAL (accessories) - Commercial trade number jug + juglid : HD7985/30 (Grey) Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification 12/08...
- Page 2 HD7690/30 DISASSEMBLY- AND RE-ASSEMBLY ADVISE REPAIR INSTRUCTION - Remove bottom base plate (3 screws). - Descaling: Regular de-scaling will prolong the life of your appliance - Now the Power module as well as the LCD/Timer module and will guarantee optimal brewing results. can be reached.
- Page 3 EXPLODED VIEW & PARTS LIST HD7690/30 Service code Description Service code Description 4222 259 38780 LCD Module 4222 459 45022 Filter insert assy Black * 4222 459 45049 Display window 4222 459 45024 Dripstop kit 4222 459 45050 Buttons 4222 459 45039 Frame Grey 4222 459 45034...
- Page 4 EXPLODED VIEW HD7690/30...
