Exporting The Remote Button Engraving Template As A DXF File

Once you have specified the text that you want to have engraved on each of the buttons on the Remote,

you can export the button engraving template as a DXF file.

DXF files are generally compatible with CAD graphics programs.

1. Select a Remote UI tab for a keypad that has button engraved text indicated.

2. Select Remote > Engraving - Export DXF File (or click the toolbar button) to open the Export

DXF File dialog.

3. Specify the filename and target directory for the exported DXF file.

4. Click Export. The system prompts you when the process is complete.

1. With a Remote UI tab selected, select Remote> Generate KeypadBuilder Project (or click the

toolbar button).

2. Edit the file name and target directory as desired, and click Save to generate the KPB project file.

132

1.1 = 110%

1.2 = 120%

1.3 = 130%

1.4 = 140%

1.5 = 150%

Click inside the text field to enable Up and Down arrows to scale the selected button text

up or down, in .10% increments.

This selection opens the Generate KeypadBuilder Project dialog, where you can edit the

name and target directory for the resulting KPB project file.

By default, the KPB file is named as follows:

VA Project Name - Keypad Name.KPB

Once it has been created, this project file can be opened and edited in the KeypadBuilder

application (available for free download from www.amx.com). Select the Open Project In

KeypadBuilder option to automatically open the resulting file once it is generated.

Refer to the KeypadBuilder on-line help for details.
