Finishing the Project

Overview

After creating a system, there are a few steps involved in finishing the project:
1. Review the Project Properties
2. Save the Project
3. Generate and Transfer System Files:
Optionally, there are a few other steps that can be taken:

Viewing And Editing Project Properties

Select System > Project Properties to open the Project Properties dialog, where you can view and edit
basic project information for the active project.
The fields in this dialog include:
The only required field in this dialog is System Name.
VisualArchitect v1.1
CONFIDENTIAL AND PROPRIETARY. COPYRIGHT, AMX LLC, 2006
Refer to the Generating The TPDesign4 Project (*.TP4) File section on page 122.
Refer to the Generating The KeypadBuilder Project (*.KPB) File For Keypads section on
page 129.
Refer to the Generating The KeypadBuilder Project (*.KPB) File For Remotes section on
page 132
Exporting Diagram Images
Printing the Diagrams
If you started your project via the Basic System Assistant dialog, some of the fields in this
dialog are pre-populated with the project data you entered there.
If you started your project via the (New) Empty System option, all fields are empty.
System Name - Enter the name that you want to associate with this system. This name will be
reflected in the resulting project (*.VAP) file, and any system reports and diagrams generated
from this project (default = Untitled).
This System Name is used as part of the filename for export diagram images, and as part of the
Header/Footer text in printouts of diagram images.
Dealer ID - Enter the name of the dealer associated with this project.
Sales Order - Enter the sales number associated with this project
File Revision - Enter a file revision number.
Designer ID - Enter the name of the designer associated with this project.
Purchase Order - Enter the sales number associated with this project.
Comments - Enter any comments that might prove useful regarding this project.
