Renesas QB-78F8069-EA-01T User Manual
Renesas QB-78F8069-EA-01T User Manual

Renesas QB-78F8069-EA-01T User Manual

Advertisement

Quick Links

QB-78F8069-EA-01T
Exchange Adapter
Target Devices
PD78F8064
PD78F8065
PD78F8066
PD78F8067
PD78F8068
PD78F8069
本資料に記載の全ての情報は本資料発行時点のものであり、ルネサス エレクトロニクスは、
予告なしに、本資料に記載した製品または仕様を変更することがあります。
ルネサス エレクトロニクスのホームページなどにより公開される最新情報をご確認ください。
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
website (http://www.renesas.com).
www.renesas.com
User's Manual
Rev.1.00 Aug 2011

Advertisement

loading
Need help?

Need help?

Do you have a question about the QB-78F8069-EA-01T and is the answer not in the manual?

Questions and answers

Summary of Contents for Renesas QB-78F8069-EA-01T

  • Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
  • Page 2: System Configuration

    PD78F8069 を用いたシステム開発において, QB-78K0RFX3を組み合わせてハードウエアおよびソフトウエアを効率的にデバッ グするエクスチェンジ・アダプタです。 また,本製品を使用する際はQB-78K0RFX3 ユーザーズ・マニュルも合わせてお読みください。 CHAPTER 1 GENERAL The QB-78F8069-EA-01T is an exchange adapter that is used in combination with the QB-78K0RFX3 to efficiently    debug hardware and software in the development of systems using the PD78F8064,...
  • Page 3 Windows PC IBM PC/AT compatible can be used <2> ID78K0R-QB Disk/Accessory Disk: Debugger, USB drivers, manual, etc. Obtain latest software from the Renesas Electronics website. <3> USB interface cable: Cable connecting QB-78K0RFX3 to host machine <4> AC adapter: Can support 100 to 240 V by replacing AC plug <5>...
  • Page 4 PD78F8068 and PD78F8069 is configured by the existing product QB-78K0RFX3 and an exchange adapter mounted with the E981.12 (IO-Link Transceiver Chip). The figure below shows the configuration. 図1−3  QB-78F8069-EA-01T構成図 Figure 1-3. QB-78F8069-EA-01T Configuration Diagram Emulation By IECUBE IECUBE Emulation IECUBE...
  • Page 5 第 2 章 セットアップの手順 QB-78F8069-EA-01T CHAPTER 2 SETUP PROCEDURE 第2章  セットアップの手順 クロックの設定 内部クロックを使用する場合,ハードウエア設定は不要です。 発振器の実装が必要な場合,QB-78K0RFX3 ユーザーズ・マニュアル 2. 2 クロックの設定を参照してください。 ソフトウエアのセットアップ QB-78K0RFX3 ユーザーズ・マニュアル 2.1 ソフトウエアのセットアップを参照してください。 コネクタ類の実装,接続 QB-78K0RFX3ユーザーズ・マニュアル 2. 3 コネクタ類の実装,接続および本書2.1 ターゲット・システムとQB-78K0RFX3の接 続を参照してください。 ユーザ・システムとQB-78K0RFX3の接続 QB-78K0RFX3 ユーザーズ・マニュアル 2. 4 ユーザ・システムとQB-78K0RFX3の接続および本書2.1 ユーザ・システムと QB-78K0RFX3の接続を参照してください。 USBインタフェース・ケーブル,ACアダプタの接続 QB-78K0RFX3 ユーザーズ・マニュアル 2. 6 USBインタフェース・ケーブル,ACアダプタの接続を参照してください。...
  • Page 6: Setup Procedure

    第 2 章 セットアップの手順 QB-78F8069-EA-01T CHAPTER 2 SETUP PROCEDURE CHAPTER 2 SETUP PROCEDURE Clock Settings If using the internal clock, hardware settings are not required. If mounting an oscillator is required, refer to QB-78K0RFX3 User’s Manual 2. 2 Clock Settings.
  • Page 7 <2> Connect the emulation probe to TCN1, TCN2 and TCN3 of the QB-78K0RFX3. <3> Connect the exchange adapter (QB-78F8069-EA-01T) and the target connector (QB-64K8-NQ-01T). <4> Connect the emulation probe to CN1, CN2 and CN3 of the exchange adapter (QB-78F8069-EA-01T). Caution Connect the exchange adapter (QB-78F8069-EA-01T) with the target connector (QB-64K8-NQ-01T) as the pin 1 positions (notches) match.
  • Page 8 第 2 章 セットアップの手順 QB-78F8069-EA-01T CHAPTER 2 SETUP PROCEDURE 図2−1  ユーザ・システムからQB-78K0RFX3までの接続 Figure 2-1. Connecting the User System and QB-78K0RFX3 QB-78K0RFX3 ② Emulation probe (QB-144-EP-02S) ④ Exchange adapter (QB-78F8069-EA-01T) ③ Target connector (QB-64K8-NQ-01T) ① User system R20UT0795XJ0100 Rev.1.00 Page 7 of 8 2011.08.26...
  • Page 9 – Use the QB-78K0RFX3 with the latest control code. – The QB-78K0RFX3 and QB-78F8069-EA-01T may be damaged if emulation is executed without voltage being applied to VDD, VDDH, IVDD1 and IVDD3 from the user system. Be sure to apply voltage from the target system when executing a debug operation.
  • Page 10 QB-78F8069-EA-01T R20UT0795XJ0100...
