Half DIN Rail 8 Form C Relay
Output Expander
SY-SIX-HPX8-DIN
Installation Manual
Document last updated June 14, 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Synergis IX and is the answer not in the manual?

Questions and answers

Summary of Contents for Genetec Synergis IX

  • Page 1 Half DIN Rail 8 Form C Relay Output Expander SY-SIX-HPX8-DIN Installation Manual Document last updated June 14, 2024...
  • Page 2 In no event shall Genetec Inc. be liable to any person or entity with respect to any loss or damage that is incidental to or consequential upon the instructions found in this document or the computer software and hardware products described herein.
  • Page 3: Table Of Contents

    Contents Introduction Installation Requirements Grounding Requirements Safety Grounding Earth Ground Connection Mounting Removal DC Power & Encrypted Module Network Outputs Outputs 1 to 8 Trouble Inputs Address Configuration LED Indicators Status Indicator Fault Indicator Power Indicator Output Indicators Error Code Indication Error Code Display Mechanical Diagram Mechanical Layout...
  • Page 4: Introduction

    Introduction The Synergis™ IX Half DIN Rail 8 Form C Relay Output Expander extends the number of outputs on the system by 8, featuring high current Form C relays for controlled automation of building systems including lighting and HVAC. Flexible module network architecture allows large numbers of modules to be connected to the RS-485 module network.
  • Page 5: Installation Requirements

    Installation Requirements This equipment is to be installed in accordance with: ⦁ The product installation instructions ⦁ AS/NZS 2201.1 Intruder Alarm Systems ⦁ The Local Authority Having Jurisdiction (AHJ) SY-SIX-HPX8-DIN | Half DIN Rail 8 Form C Relay Output Expander | Installation Manual Last updated June 2024...
  • Page 6: Grounding Requirements

    Grounding Requirements An effectively grounded product is one that is intentionally connected to earth ground through a ground connection or connections of sufficiently low impedance and having sufficient current-carrying capacity to prevent elevated voltages which may result in undue hazard to connected equipment or to persons.
  • Page 7 DIN Rail Ground Connections (one or more cabinets installed in the same room) Module Network (RS-485 N+, N-, NA, NB) DIN Rail Enclosure Additional DIN Rail Enclosure(s) Controller Reader Expander Dialer’s Earth Ground Connection Power Supply Input Expander Output Expander AC Mains Wiring Earth Ground Link Connection...
  • Page 8: Mounting

    Mounting Synergis™ IX half DIN rail modules are designed to mount on standard DIN rail either in dedicated DIN cabinets or on generic DIN rail mounting strip. They can also be hung from the top mount screw and permanently fastened using the hole in the attachment clip.
  • Page 9: Dc Power & Encrypted Module Network

    DC Power & Encrypted Module Network The expander incorporates encrypted RS-485 communications technology, and both module and network power are supplied by the N+ and N- terminals. Network communications input from the Controller or previous module Connection of the communications and DC supply should be performed according to the diagram shown above.
  • Page 10: Outputs

    Outputs The output expander has 8 programmable outputs. These outputs are used to activate bell sirens, lighting circuits, door locks, relay accessory products and other automation points. Outputs 1 to 8 The 8 outputs each have a Form C output relay. The connection example below shows the control of an external LED indicator.
  • Page 11: Trouble Inputs

    Trouble Inputs Each output expander can monitor up to 8 trouble inputs. Trouble inputs are used to monitor the module status and in most cases are not physically connected to an external input. The following table details the trouble inputs that are configured in the system and the trouble groups that they are associated with.
  • Page 12: Address Configuration

    Address Configuration The module address is configured via programming and will require knowledge of the module serial number. The serial number can be found on the identification sticker on the product. Refer to the Synergis™ IX system controller configuration guide for address programming details. The controller has a set limit on the number of modules of each type that it can support.
  • Page 13: Led Indicators

    LED Indicators Synergis™ IX DIN rail modules feature comprehensive diagnostic indicators that can aid the installer in diagnosing faults and conditions. In some cases an indicator may have multiple meanings depending on the status indicator display at the time. Status Indicator The status indicator displays the module status.
  • Page 14: Output Indicators

    Output Indicators The output indicators will show the status of the outputs. State Description Constantly on (red) Output is ON Constantly off Output is OFF SY-SIX-HPX8-DIN | Half DIN Rail 8 Form C Relay Output Expander | Installation Manual Last updated June 2024...
  • Page 15: Error Code Indication

    Error Code Indication When the module attempts to register or communicate with the system controller a registration error can be generated indicating that it was not successful. Error Code Display The following table is only valid if the fault indicator is constantly on and the status indicator is flashing...
  • Page 16: Mechanical Diagram

    Mechanical Diagram The mechanical diagram shown below outlines the essential details needed to help ensure the correct installation of the output expander. 12VDC Pass Through 12VDC Pass Through Relay Output 4 Relay Output 3 Relay Output 8 Relay Output 7 Output Indicators Status Indicators Relay Output 5...
  • Page 17: Mechanical Layout

    Mechanical Layout The mechanical layout shown below outlines the essential details needed to help ensure correct installation and mounting. All measurements are shown in millimeters. 78.40 Front 78.40 39.20 39.20 Back 67.18 SY-SIX-HPX8-DIN | Half DIN Rail 8 Form C Relay Output Expander | Installation Manual Last updated June 2024...
  • Page 18: Technical Specifications

    Technical Specifications The following specifications are important and vital to the correct operation of this product. Failure to adhere to the specifications will result in any warranty or guarantee that was provided becoming null and void. Ordering Information SY-SIX-HPX8-DIN Synergis™ IX Half DIN Rail 8 Form C Relay Output Expander Power Supply DC Input Voltage 11-14VDC...
  • Page 19 Genetec Inc. continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (www.genetec.com) for the latest documentation and product information. SY-SIX-HPX8-DIN | Half DIN Rail 8 Form C Relay Output Expander | Installation Manual...
  • Page 20: New Zealand And Australia

    New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. SY-SIX-HPX8-DIN | Half DIN Rail 8 Form C Relay Output Expander | Installation Manual Last updated June 2024...
  • Page 21: European Standards

    European Standards CE Statement Conforms where applicable to European Union (EU) Low Voltage Directive (LVD) 2014/35/EU, Electromagnetic Compatibility (EMC) Directive 2014/30/EU, Radio Equipment Directive (RED)2014/53/EU and RoHS Recast (RoHS2) Directive: 2011/65/EU + Amendment Directive (EU) 2015/863. This equipment complies with the rules, of the Official Journal of the European Union, for governing the Self Declaration of the CE Marking for the European Union as specified in the above directive(s).
  • Page 22 Tests EMC (operational) according to EN 55032:2015 Radiated disturbance EN 55032:2015 Power frequency magnetic field immunity tests (EN 61000-4-8) To comply with EN 50131-1, EN 60839-11 Security Grade 4 and AS/NZS2201.1 class 4&5 Vibration Detection for PreTamper Alarm, protection is provided by a DSC SS-102 Shockgard Seismic vibration sensor mounted within the system enclosure.
  • Page 23: Uk Conformity Assessment Mark

    UK Conformity Assessment Mark General Product Statement The UKCA Compliance Label indicates that the supplier of the device asserts that it complies with all applicable standards. SY-SIX-HPX8-DIN | Half DIN Rail 8 Form C Relay Output Expander | Installation Manual Last updated June 2024...
  • Page 24: Fcc Compliance Statements

    FCC Compliance Statements FCC Rules and Regulations CFR 47, Part 15, Subpart B This equipment complies with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. Operation is subject to the following two conditions: ⦁...
  • Page 25: Industry Canada Statement

    Industry Canada Statement ICES-003 This class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. CAN ICES-3 (A)/NMB-3(A) SY-SIX-HPX8-DIN | Half DIN Rail 8 Form C Relay Output Expander | Installation Manual Last updated June 2024...
  • Page 26 © Genetec Inc., 2024. Genetec™, Synergis™ IX, Synergis™ IX, the Synergis™ IX logo and the Genetec™ Logo are trademarks of Genetec Inc., and may be registered or pending registration in several jurisdictions. Other trademarks used in this document may be trademarks of the manufacturers or vendors of the respective products.
