ASSEMBLY INSTRUCTION FOR ACME FURNITURE
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware. Compare
with parts list to be sure all parts are present. If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service, please indicate the model number and code letter of part(s) needed.
***Do not fully tighten screws until fully assembled***
DESCRIPTION
○
1
○
2
○
3
○
4
○
5
MODEL#72590ST/72591GL
STRETCHER #1
STRETCHER #2
STRETCHER #3
LONG BOLT
GLASS TOP
COMPONENT PARTS
PART NAME
STOPPER
Q'TY (PCS)
2
12
2
4
1
PAGE 1/5
