*** Thank you for purchasing this quality product. Be sure to check all packing materials carefully

for small parts which may have come loose inside the carton during shipment. Identify and count

all parts and compare with parts list below.

*** Assemble product on a flat, soft surface such as a carpet or cloth to prevent scratching the

finish. Read all instruction and study the drawings carefully before starting the assembly process.

IMPORTANT: Do not tighten bolts completely until all

bolts are completely lined up and inserted into holes

ASSEMBLY INSTRUCTIONS

Item No: #36135F

PAGE 1 OF 7

Need help?

Do you have a question about the 36135F and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS Item No: #36135F *** Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts which may have come loose inside the carton during shipment. Identify and count all parts and compare with parts list below.
Page 2: Parts List
PARTS LIST HARDWARE LIST DIAGRAM PART NAME Q'Ty DIAGRAM PART NAME Q'Ty 1 pc Headboard Bolt 7.8 x 90 (mm) 8 pcs 1 pc Footboard Flat Washer: 7.8 x 29 x 8 (mm) 8 pcs Side Rails 2 pcs Hex Nut: 7.8 x 13 x 10 (mm) 8 pcs Support Leg 2 pcs...
Page 3 #36135F is packed in 3 cases Disignation Part Hardware Carton Item: Headboard #36125F-HB x 1pc Footboard Item: x 1pc #36136F-FB Slats x 13pcs Side Rails A :Bolt x 8pcs x 2pcs B :Flat Washer x 8pcs Item: Support Leg #36137F-R...
Page 4: Step 1: Handle Assembly
STEP 1: HANDLE ASSEMBLY Leveler STEP 2: HANDLE ASSEMBLY PAGE 4 OF 7...
Page 5 STEP 3: REMOVE THE DRAWER Leveler STEP 4: HEADBOARD - FOOTBOAD - SIDE RAIL ASSEMBLY 8 pcs 8 pcs 8 pcs 4 PLACES 1 pc PAGE 5 OF 7...
Page 6 STEP 5: SUPPORT LEG ASSEMBLY STEP 6: SLAT ASSEMBLY 3 pcs PAGE 6 OF 7...
Page 7 STEP 7: SLAT ASSEMBLY SLAT ASSEMBLY 26 pcs 26 PLACES STEP 8: ASSEMBLY IS COMPLETED PAGE 7 OF 7...
