ITEM NO. 72590 COUNTER HIGH TABLE
1
STRETCHER # 1
2PCS
4
STOPPER
LONG BOLT
4PCS
A
BOLT 3/16" X 3/8"
28PCS
D
FLAT WASHER
4PCS
ASSEMBLY
STRETCHER # 2
12PCS
GLASS TOP
LEVELER
4PCS
ALLEN KEY
INSTRUCTIONS
2
5
1PC
B
E
1PC
3
STRETCHER # 3
2PCS
C
NUT
4PCS
F
OPEN WRENCH
1PC
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Acme Furniture 72590
Summary of Contents for Acme Furniture 72590
- Page 1 ITEM NO. 72590 COUNTER HIGH TABLE ASSEMBLY INSTRUCTIONS STRETCHER # 1 STRETCHER # 2 STRETCHER # 3 2PCS 12PCS 2PCS STOPPER LONG BOLT GLASS TOP 4PCS BOLT 3/16” X 3/8” LEVELER 28PCS 4PCS 4PCS FLAT WASHER ALLEN KEY OPEN WRENCH...
- Page 2 *** Do not tighten screws & bolts until the entire unit is completely assembled. *** STEP 1 *Please put all parts on a soft surface to prevent scratches. Screw long bolts (4) into the corresponding holes on the STOPPER glass top (5) as shown and tighten it.
- Page 3 STEP 3 Insert attached long bolts (4) through the corresponding holes on stretchers (2) as shown and fix stretchers (2) to stretchers (1) by using bolts (A) as shown. Then following with next stretchers (2) one by one. *Do not tighten the bolts until the frame is built up.
- Page 4 STEP 5 Attach stretchers (3) to stretchers (2) by using bolt (A) as shown then tighten all bolts firmly. Fix the frame firmly by using nuts (C) and flat washers (D) with open wrench (F) as shown. Attach levelers (B) to the bottom of stretchers (3) then turn the assembled unit right side up carefully.
