HARDWARE DESCRIPTION
HWKT-00008X
M8-1.25 X 30MM CLASS 8.8
FLBW-
FLANGED CAP SCREW
00894X
W/WASHER ZINKLAD 1000B
CLIP –
M8-1.25 X 20MM-BARREL CLIP
00643X
ZINKLAD1000B
PARTS INCLUDED
DRIVER SIDE
PASSENGER SIDE
12302 Shiloh Church Rd. Houston TX 77066
REVISION - -
QTY.
12
12
QTY
1
1
Step 1: Locate the driver side step rail.
DRIVER
© 2018 N-FAB, INC.
I-SHEET NUMBER: INST-00132
PART NUMBER: 415418312
PRODUCT: NERF STEPS
APPLICATION: 15-20 COLORADO/CANYON
cab
CREW
PASSANGER
Phone (281) 880-6322 - Fax (281) 880-6325
REVISION DATE 08/01/19
Advertisement
Related Manuals for Truck Hero N-FAB INST-00132
Summary of Contents for Truck Hero N-FAB INST-00132
- Page 1 I-SHEET NUMBER: INST-00132 PART NUMBER: 415418312 PRODUCT: NERF STEPS APPLICATION: 15-20 COLORADO/CANYON CREW HARDWARE DESCRIPTION QTY. HWKT-00008X M8-1.25 X 30MM CLASS 8.8 FLBW- FLANGED CAP SCREW 00894X W/WASHER ZINKLAD 1000B CLIP – M8-1.25 X 20MM-BARREL CLIP 00643X ZINKLAD1000B PARTS INCLUDED DRIVER SIDE PASSENGER SIDE Step 1: Locate the driver side step rail.
- Page 2 Step 2: Locate the rubber body plugs on the underside of the body. There will be 3 sections of 2 plugs each. One near the top of the body and one near the bottom. Fig. A Body Plugs Fig. A Step 3: Using the measurement from the brackets, only remove the rubber plugs from the sections you will need to mount the step.
