Kuryakyn 2098 Installation

BULLET LIGHT REAR TURN SIGNAL BAR 2098
PARTS INCLUDED
1 Bar/Lights/License Plate Light Assembly—Chrome
1 License Plate Bracket—Chrome
1 Hardware Kit Including:
2 5/16"-18 x 5/8" Hex Head Flange Screws
2 1⁄4"-20 x 1⁄2" Button Socket Cap Screws
1 Adhesive Foam Pad
1 Alcohol Pad
2 Female T-Tap Connectors
2 Insulated Male Spade Connectors
10 Pin Terminals
10 Socket Terminals
4 Ring Terminals
1 Connector Kit Including:
2 Wired Male Connector Plugs
4 3mm x 3⁄4" Long Heat Shrink Tubing
10 4" Cable Ties
1 Installation Instructions
Please read and understand entire instructions before starting installation.
THANK YOU FOR CHOOSING K
IN ORDER TO PROTECT YOU AND OTHERS FROM POSSIBLE INJURY AND/OR
PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION TO ALL
INSTRUCTIONS, WARNINGS, CAUTIONS AND NOTICES REGARDING THE USE
AND CARE OF THIS PRODUCT.
IF INSTALLING THIS PRODUCT FOR ANOTHER PARTY,
PLEASE MAKE SURE THEY RECEIVE THIS COPY OF THE
INSTALLATION INSTRUCTIONS SO THEY ARE AWARE OF
THE IMPORTANT INFORMATION CONTAINED IN THEM.
TOOLS SUGGESTED
Set of Combination Wrenches, Set of Hex Wrenches, Phillips Screwdriver, Wire Cutter/Crimper,
Soldering Iron and Solder, Test Light
STRICTLY OBSERVE THE FOLLOWING GUIDELINES IN ORDER TO USE THE
PRODUCT PROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.
STEP 1
Read and understand all steps in the instructions before starting the
installation. Park the motorcycle on a hard, level surface and turn off the
ignition.
-cont.-
2098-24HD-1112
ϋ
RYAKYN!
THIS INDICATION ALERTS YOU TO THE FACT THAT
IGNORING THE CONTENTS DESCRIBED HEREIN CAN
RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
This indication alerts you to the fact that ignoring the
contents described herein may negatively affect product
performance and functionality.
INSTALLATION
CUSTOMER SERVICE
877.370.3604 (toll free)
INSTALLATION QUESTIONS
techsupport@kuryakyn.com
or call 715.247.2983
LIMITED WARRANTY
Küryakyn warrants that any Küryakyn products
sold hereunder, shall be free of defects in
materials and workmanship for a period of one
(1) year from the date of purchase by the
consumer excepting the following provisions:
● Küryakyn shall have no obligation in the event
the customer is unable to provide a receipt
showing the date the customer purchased the
●The product must be properly installed,
maintained and operated under
normal conditions.
●Küryakyn makes no warranty, expressed or
implied, with respect to any gold plated
●Küryakyn shall not be liable for any
consequential and incidental damages, including
labor and paint, resulting from failure of a
Küryakyn product, failure to deliver, delay in
delivery, delivery in nonconforming condition, or
for any breech of contract or duty between
Küryakyn and a customer.
●Küryakyn products are often intended for use in
specific applications. Küryakyn makes no
warranty if a Küryakyn product is used in
applications other than intended.
●Küryakyn electrical products are warranted for
one (1) year from the date of purchase by the
consumer. L.E.D.'S contained in components of
Küryakyn products will be warranted for defects
in materials and workmanship for 3 years from
the date of purchase where as all other
components shall be warranted for one(1) year.
This includes, but is not limited to; control
modules, wiring, chrome & other components.
●Küryakyn makes no warranty of any kind in
regard to other manufacturer¹s products
distributed by Küryakyn. Küryakyn will pass on
all warranties made by the manufacturer and
where possible, will expedite the claim on behalf
of the customer, but ultimately, responsibility for
disposition of the warranty claim lies
with the manufacturer.
ABOUT OUR CATALOG
For purchasing Küryakyn® products, you
can receive a complete catalog free of charge.
Send the Proof-of-Purchase below with
your address to: Küryakyn, P.O. Box 339,
Somerset, WI 54025.
Please indicate either Accessories Catalog for
Harley-Davidson® or GL & Metric Cruisers.
Be sure to ask your local dealer about other
Küryakyn® products, the motorcycle parts and
accessories designed for riders by riders.
©2005 Küryakyn USA® All Rights reserved.
product(s).
products.
