Kuryakyn 2635 Installation Instructions

WINDSHIELD CENTER TRIM FOR ROAD GLIDE, GLOSS BLACK
Thank You For Choosing Küryakyn!
Protect yourself and others from potential injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices
regarding the installation, use, and care of this product.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
1 Windshield Center Trim
1 Installation Instructions
YOU WILL ALSO NEED:
Phillipshead screwdriver, warm, soapy water and clean rag
STEP 1 Read and understand all steps in the instructions before starting the installation. Park the motorcycle on a hard, level surface and turn
IGN OFF.
STEP 2 Remove the existing screws that secure the windshield to the outer fairing; save them,
they will be reused. Set the fairing on a soft, clean work surface.
STEP 3 Refer to PIC 1. Using warm, soapy water and a clean rag, remove all dirt and debris
from the installation area; rinse and allow the area to dry completely.
Clean the windshield with warm, soapy water; rinse and allow to dry completely.
STEP 4 Refer to PIC 2. Press the channel of the Trim onto the windshield; ensure that it
is centered.
2635-11HD-0915
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN
RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
This indication alerts you to the fact that ignoring the contents described herein may negatively affect product per-
formance and functionality or damage the product itself or the product to which it is being attached.
These installation instructions contain important information. Ensure that the end user receives this copy and is
aware of its importance for future use.
PIC 1
CLEAN + DRY
PIC 2
PRESS CHANNEL ONTO WINDSHIELD
2635
Page 1
