- Page 1 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 INSTALLATION INSTRUCTIONS VORTEX RUNNING BOARD FOR LEXUS RX350 10-15 PART # VO-LX25OE Page 1 of 9 10/23/12 (DP)
-
Page 2: Parts List
VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 PARTS LIST: Driver Side Running Board 10mm Plastic Retainer 10mm x 50mm “T” Bolts (Rear Bracket only) Passenger Side Running Board Driver Side Front Mounting Bracket 10mm x 35mm Button Head Bolt Plates Passenger Side Front Mounting Bracket 10mm x 25mm Hex Bolts Driver Side Center Mounting Bracket... - Page 3 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 5. Hold the assembly in place by the handle on the Tool and apply pressure to keep the Insert in the hole. Tighten the Hex Bolt on the assembly until Insert is fully compressed/expanded and locked in place, (Fig.
- Page 4 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 9. Carefully unwrap and select the driver side Running Board. Insert (3) 6mm T-Bolts into each slot in the end of the channels, (3 T-Bolts per channel), on the bottom of the Running Board, (Fig. 19). Hold the Running Board up in approximate position and slide the T-Bolts down to line up with the (3) Mounting Brackets.
- Page 5 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 6mm Hex Bolt 10mm Hex Bolt NOTE: To insert a 10mm 6mm Lock Washer 10mm Lock Washer Threaded Insert into the 6mm Flat Washer 10mm STD Flat Washer large factory hole, check Front for fit and/or use 1/2"...
- Page 6 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 Remove plastic plugs on side and bottom of frame channel Front (Fig 10A) Use Plastic Retainer to hold Bolt Plate in place during Bracket installation 10mm Threaded Insert 10mm Flat Washer 10mm Flange Nut (Fig 10B) Driver side center mounting location pictured 10mm Hex Bolt...
- Page 7 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 Front 10mm Bolt Plate 10mm Plastic Retainer 10mm Threaded Insert Remove rubber plug (Fig 14) Passenger/Right side center Bracket mounting location pictured Rear (Fig 15) Driver side rear mounting location Rear (Fig 16A) 10mm T-Bolt Rear (Fig 16B) Insert T-Bolt then rotate 90-degrees to go across oval hole...
- Page 8 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 Rear 10mm Flat Washer 10mm Flange Nut Insert T-Bolts into channel and slide into position Front (Fig 18) Driver side rear Mounting Bracket Front Fig 19 6mm x 22mm Flat Washers 6mm Lock Washers 6mm Hex Nuts Fig 20 Front...
- Page 9 VORTEX RUNNING BOARD BRACKETS FOR LEXUS RX350 10-15 Front Front (Fig 22B) Hold plastic cover up in position to determine area to cut from cover. Driver side front cover pictured Front (Fig 23A) Driver side front cover pictured Front (Fig 23B) Cut cover only enough to clear Bracket.
