- Page 1 TEL：1-866-XANATOS INSTALLATION INSTRUCTIONS SENSOR RELOCATION KIT 3” ROUND BULL BAR 2020-23 SILVERADO 2500-3500 2019-23 RAM 1500(EXCL. REBEL & TRX TRIMS, 19-23 RAM 1500 CLASSIC AND 20-22 RAM 1500 DIESEL MODELS) PART#BPS02B...
- Page 2 SENSOR RELOCATION KIT 3” ROUND BULL BAR 2020-23 SILVERADO 2500-3500 2019-23 RAM 1500(EXCL. REBEL & TRX TRIMS, 19-23 RAM 1500 CLASSIC AND 20-22 RAM 1500 DIESEL MODELS) Part List: Driver/left Sensor Housing Rubber Grommets Passenger/right Sensor Housing 8-1.25mm x 20mm Button Head Bolts Driver/left side Housing Back Cover 8mm x 16mm x 1.6mm Flat Washers Passenger/right Housing Back Cover...
- Page 3 SENSOR RELOCATION KIT 3” ROUND BULL BAR 2020-23 SILVERADO 2500-3500 2019-23 RAM 1500(EXCL. REBEL & TRX TRIMS, 19-23 RAM 1500 CLASSIC AND 20-22 RAM 1500 DIESEL MODELS) the sensor mount in the Housing, (Figure 8). Place (1) Foam Spacer over the sensor and snap the Retaining Cap onto the tabs on the Sensor Mount.
- Page 4 SENSOR RELOCATION KIT 3” ROUND BULL BAR 2020-23 SILVERADO 2500-3500 2019-23 RAM 1500(EXCL. REBEL & TRX TRIMS, 19-23 RAM 1500 CLASSIC AND 20-22 RAM 1500 DIESEL MODELS) Driver/Left Side Installation Pictured (Fig 3) Slide (2) Rubber Grommets onto Wire Harness Extension (Fig 4) Plug Harness Extension into factory harness.
- Page 5 SENSOR RELOCATION KIT 3” ROUND BULL BAR 2020-23 SILVERADO 2500-3500 2019-23 RAM 1500(EXCL. REBEL & TRX TRIMS, 19-23 RAM 1500 CLASSIC AND 20-22 RAM 1500 DIESEL MODELS) Retaining Cap Foam Spacer Front (Fig 7) Remove silicone seal from sensor. Slide large Seal over end of sensor (sensor Foam used for example only) Washer...
- Page 6 SENSOR RELOCATION KIT 3” ROUND BULL BAR 2020-23 SILVERADO 2500-3500 2019-23 RAM 1500(EXCL. REBEL & TRX TRIMS, 19-23 RAM 1500 CLASSIC AND 20-22 RAM 1500 DIESEL MODELS) Front (2) 6mm Combo Bolts (Fig 11) Attach Back Cover to driver/left Housing. Push Grommet into hole in Cover 4-3/4”...
