Black Horse Off Road B046409-SP Installation Instructions

PARTS LIST:

1 Bull Bar
1 Driver/Left Mounting Bracket
1 Passenger/Right Mounting Bracket
4 12mm Bolt Plates

PROCEDURE:

1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS
CAREFULLY BEFORE STARTING INSTALLATION.
2. NOTE: It may be necessary to remove/relocate front license plate and license plate bracket. It is not
required, but strongly recommended. If local/state law requires a license plate, license plate relocation
kit is available through your local retailer store.

Vehicles with Factory Tow Hooks

3. Remove tow hooks by removing the front bolt and loosening rear bolt. Slide tow hooks off. Remove rear
bolt and make sure nut plate in frame stays aligned with holes.
4. Position Bottom Brackets up to bottom frame and secure them with factory tow hook bolts (Figure 1).

Vehicles without Tow Hooks

5. Insert two bolt plates through the end of frame and into bottom frame holes. NOTE: It may be
necessary to remove the lower plastic portion of the bumper to gain access to ends of frame rails. The
indented pockets in the lower bumper will need to be cut out to allow bottom brackets to pass trough.
6. Position Bottom Brackets up to bottom frame and trough Bolt Plates and secure them with the included
(4) 12mm Flat Washers, (4) 12mm Lock Washers, and (4) Hex Nuts (Figure 2).
7. Position Bull Bar on the outer side of Mounting Brackets. Attach Bull Bar to Mounting Brackets using
the included (4) 10mm x 30mm Hex Head Bolts, (4) 10mm Lock Washers, (4) 10mm Hex Nuts, and (8)
10mm Flat Washers.
8. Adjust Bull Bar properly, and then tighten all hardware at this time.
9. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to add a
protective layer over the finish. Do not use any type of polish or wax that may contain abrasives that could
damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild
soap may be used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
INSTALLATION INSTRUCTIONS
BULL BAR PART#: BB046409-SP\BB046409A-SP
04-07 FORD F-150 2/4 WHEEL DRIVE /
06-07 LINCOLN MARK LT/07 FORD EXPEDTION
4 12mm Flat Washers
4 12mm Lock Washers
4 12mm Hex Nuts
8 10-1.50mm x 30mm Hex Head Bolts
14 10mm Flat washers
8 10mm Lock Washers
6 10mm Hex Nuts
