Acme Furniture Haiden 28453 Assembly Instruction

ASSEMBLY INSTRUCTION FOR ACME FURNITURE
Thank you for purchasing the quality product.Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment.Separate,indentify and count all parts and metal hardware. Compare
with all parts list to be sure all parts are present.If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service,please indicate the model number and code letter of parts(s) needed.
DESCRIPTION
1
2
HARDWARE REQUIRED(BOX OF NIGHSTAND)
A
B
C
D
How to assemble:
Step 1:
1
Step 2:
2
C
B
D
A
Attention:
*** Some number parts listed in the instruction sheet may not be in parts bags as they already be assembled.
Carefully check parts and packing materials prior to ordering replacements.
MODEL # 28453/28433
***Do not fully tighten screws until fully assembled***
COMPONENT PARTS
PART NAME
NIGHT STAND
LEG
BOLT 1/4" x 2" - 4 PCS
SPRING WASHER 1/4"- 4 PCS
FLAT WASHER 1/4"- 4 PCS
ALLEN KEY M4 x 2 1/2"- 1 PC
Hardware Pack
2
Remark : Turn the Night Stand
to upright position as shown.
Soft Surface
Step 3:
COMPLETE
Q'TY (PCS)
1
4
Step 3.1
Step 3.2
