Acme Furniture Gorsedd 82440 Assembly Instruction

Thank you for purchasing the quality product. Be sure to check all packing material carefully for small parts
which may have come loose inside the carton during shipment. Separate, Identify and count all parts and
metal hardware. Compare with all parts listed to be sure all parts are present. If any part(s) are missing or
damaged, please contact your local furniture dealer. For efficient and speedy service, please indicate the
model number and code letter of part(s) needed.
TOP PLATE*1PC
A:
How to assemble & Steps
Attention
***Some number parts listed on the instruction sheet may not be in parts bag as they may be assembled.
Carefully check parts and packing materials prior to ordering replacements. ***
ASSEMBLY INSTRUCTION FOR ACME FURNITURE
CLEANING INSTRUCTIONS
Clean the surface with a furniture polish and a soft cloth
MODEL# 82440
**Do not fully tighten screws until fully assembled**
Drawing
NO.
1
2
3
4
LEGS*4PCS
B:
A
HARDWARE LIST:
Description
FLAT WASHER ( 5/16"x 19mm)
SPRING WASHER( 5/16")
BOLT( 5/16"x2-1/2")
WRENCH(12mm)
3 4
2
1
Q'ty
8PCS
8PCS
8PCS
1PC
B
PAGE 1/1
