ITEM NO.84651
1
METAL FRAME
1PC
A
BOLT 3/16" X 3/8"
6PCS
* Do not tighten screws & bolts until the entire unit is completely assembled. ***
STEP 1
ASSEMBLY
2
LEGS
3PCS
B
BOLT 3/16" X 3/4"
3PCS
INSTRUCTIONS
3
TRAY
1PC
C
SCREW M8 X 7/8"
4PCS
4
USB DEVICE
1PC
D
SCREW
2PCS
*Please put all parts on a
soft surface to prevent
scratches.
Attach one of legs (2) to
metal frame (1) by using
bolts (A) as shown.
