ITEM NO. 82298
SIDE TABLE
1
SIDE PANEL
2PCS
A
BOLT 1/4"x50mm
4PCS
*** Do not tighten screws & bolts until the entire unit is completely assembled. ***
STEP 1
Attach side panels (1) to stretcher (2) using bolts (A) as
shown.
1
2
A
A
ASSEMBLY
2
STRETCEHR
2PCS
B
BOLT 1/4"x12mm
4PCS
1
A
A
2
INSTRUCTIONS
3
TABLE TOP
1PC
C
CAP
4PCS
STEP 2
Attach table top (3) to the assembled metal base using
bolts (B) as shown. Then, tighten all bolts firmly. Use
caps (C) to cover bolts (A).
C
D
ALLEN KEY
1PC
3
B
B
B
B
C
C
C
