O
AZKOYEN
1. Features and models of the B series.......2
2. Weight and dimensions.............................5
3. Conditions of use and regulations...........7
3.1 Electricity supply main conditions
3.2 Cooling
3.3 temperature and relative humidity...................................8
3.4 Maximun incline
3.5 Sound level
3.6 Types of products to be sold...........................................9
3.7 Coins that it can opera te with.......................................10
3.8 EC declaration of conformity
4. Description of the main components.....11
4.1 Door assembly
4.2 Cabinet assembly............................................................12
5. Installation and adjustment of the
machine................................................13
5.1 Electrical installation
5.2. Levelling the machine...................................................14
5.3 Ventilación necesaria.....................................................15
5.4 Encendido
5.5 Adaptations of the extraction system...........................16
5.6. Initial product loading....................................................29
5.7. Loading coin return device...........................................31
5.8. Programming the sales prices
5.9. Change of price labels
5.10. Operation verification..................................................33
Technical manual
Contents
Contents
- 1 -
Advertisement
Related Manuals for Azkoyen PALMA B6
Summarization of Contents
Conditions of Use and Regulations
Electricity Supply Mains Conditions
Voltage must match machine plate, not deviate more than 6% or 10%.
Cooling System Operation
Programmable thermometer controls internal temperature, minimum 3°C, uses R-134a coolant.
Temperature and Humidity Requirements
Optimal environment is 5°C to 32°C with 35-65% relative humidity.
Maximum Allowable Incline
Machine operates correctly with a maximum incline of 2.5° (front/side), never lay flat.
Sound Level Specifications
The sound level of this machine range does not exceed 70 dB under any circumstances.
Product Sales Compatibility
Products to be sold must have a minimum weight of 30 Grs. and a maximum of 500 Grs.
Coin and Tender Acceptance
Operates with factory-set legal tenders from any country, up to 15 types validated.
EC Declaration of Conformity
Certifies compliance with specific EC directives for machines, low voltage, and EMC.
Description of Main Components
Door Assembly Details
Details components like recovery motor, coin mechanism support, display, and money box.
Cabinet Assembly Components
Describes cabinet parts: insulating door, wall separators, adjustable legs, product collector, cold group.
