Technical Information
ZENSIA
Avda. San Silvestre, s/n
31350 Peralta (Navarra) Spain
Tel.: +34 948 709 709
www.sat.azkoyen.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZENSIA and is the answer not in the manual?

Questions and answers

Related Manuals for Azkoyen ZENSIA

Summary of Contents for Azkoyen ZENSIA

  • Page 1 Technical Information ZENSIA Avda. San Silvestre, s/n 31350 Peralta (Navarra) Spain Tel.: +34 948 709 709 www.sat.azkoyen.com...
  • Page 2 I N D E X INTRODUCTION 1.1. DEFINITIONS 1.2. PRINCIPLE TECHNICAL CHARACTERISTICS DESCRIPTION OF COMPONENTS INSTALLATION AND START UP 3.1. UNPACKING 3.2. START UP ERRORS 4.1. ERROR MESSAGES SHOWN ON THE DISPLAY 4.2 CONTROL POINTS CLEANING AND MAINTENANCE WORKING CONDITIONS AND NORMS DIMENSIONS 2ª...
  • Page 3 INTRODUCTION The automatic vending machines in the Zensia range are designed to elaborate and vend espresso coffee and instant drink powder mixed with hot water. The final product is served to the customer in a plastic cup. In the rest of this document, the names of the following components indicated below will be abbreviated as shown below: The machines in the Zensia range, as “machine or machines”.
  • Page 4 MODELS The Zensia series is comprised of the models LE and LI.  The LE model elaborates espresso coffee and instant products.  The LI only elaborates instant products. 1.2. PRINCIPLE TECHNICAL CHARACTERISTICS On automatic: the press of the finger is enough to elaborate any service; espresso ...

  • Page 5: Description Of Components

    DESCRIPTION OF COMPONENTS PRINCIPLE COMPONENTS Mains switch. Allows the mains power to be disconnected from all the components in the machine Waste liquids bucket. It collects all the waste liquids that the machine generates. It has a capacity of 8 litres. When it reaches a determined level, a device is activated that puts the machine in “out of order”...
  • Page 6 Group and piston. These are made of plastic resins and are the elements where the machine makes the infusion with the dosage of ground coffee. The group has moving parts activated by 24 Vdc motor that rotates the flywheel that moves the coffee holder from the dosage device to the piston.
  • Page 7 C1. Piston C2. Group C3. Filter C4. Holding lever C5. Extraction button C6. Position Microswitch C7. Lever for moving the group C8. Group motor The piston has a spring and two spacers that, depending on where they are placed, adjust the pressure of the piston for the quantity of ground coffee in the dosage.
  • Page 8 For this task, Azkoyen has available in its catalogue, the appropriate tool which is part number 10040130. 2ª...
  • Page 9 During the beating process, the EVs of the instant products is very important; they allow the hot water from the boiler into the beaters to elaborate the instant products. These are housed on a brass support that is at a constant temperature, because it is fixed to the hot water boiler.
  • Page 10 Soluble product hoppers The capacity in volume of the hoppers of instant product is of 6 litres. The approximate weight of the product is: Capacity in grams Product Zensia ESP Zensia INS Instant coffee 1,500 1,500 Decaffeinated 1,500 1,500 Milk...
  • Page 11 2º Remove the screws and the holding plate as indicated in the photograph. 3º Pull upwards on the extractor to free the holding tabs from the support. 2ª 10028 – E 03 - 2016...
  • Page 12 The sugar and stirrer extractor can be separated from the cup extractor. First disconnect the power loom by removing the cover that protects the cup extractor, then free the clip and pull upwards as indicated the figure. 2ª 10028 – E 03 - 2016...
  • Page 13 H1. Clip H2. Sugar and stirrer motor extractor H3. Cup motor extractor H4. Cup holder motor H5. Cup support arm H6. Cup support motor H7. Electronic circuit board H8. Cup extractor switch H9. Cup detection photo-cells H10. Hopper position microswitch H11.
  • Page 14 A10. Coin System The models of the Zensia range can work with coin changers that have executive or MDB protocol. On the left of door there is a space with 3 screws to hang the coin changer. The connectors for the coin changer are on the top of the changer.
  • Page 15 A11. Waste liquid tray It collects the possible drops of water or any other liquid after making a vend. It channels them to the waste liquid bucket. To remove it, unscrew the white screw and pull on the tray to release it from its mounting. A12.
  • Page 16 A14. Selection panel In the Zensia models, the product selection buttons are touch sensitive; to select a product it is not necessary to press a button, just put one’s finger near the product required and the machine detects its presence, which activates the service of the product requested.
  • Page 17 A15. Water inlet Electro-valve This allows water from the mains to enter the cold water deposit. It works on 230 Vac. It has a security mechanism for cases where solids, such as scale or any other solids, or the EV does not close properly and does not cut the entry of water into the machine.
  • Page 18 A16. Volume meter This meter measures the quantity of water that the pump sends for the elaboration of coffee espresso. Inside there is a flow meter with two small electro-magnets that spin with the flow of water. As it spins, 5 Vdc electrical pulses are sent to the infusion board.
  • Page 19 K1. By-pass K2. Anti-return valve When the product to be elaborated is an instant product, there is no resistance for the water to go from the boiler to the beater, so that when instant products are elaborated, the pump operates at a lower pressure than when an espresso coffee is elaborated. The pump has an anti-return valve that prevents the water returning to the boiler.
  • Page 20 A19. Hot water boiler for espresso machines The boiler works under pressure. Its capacity is 320cc of water. It heats the water for both products, espresso coffee and instant products. L1. Temperature sensor (PTC) L2. Security thermostat: switches off at 120º C L3.
  • Page 21 N1. 3 way closed N2. To infusion group N3. Entry of water from the boiler When the machine finishes elaborating an espresso coffee, the 3-way EV goes to rest position, so that the water outlet from the boiler and the group are connected to the third outlet. This way, the water that didn’t pass through the coffee, and that is retained in the group, is taken through the third channel to the residue bucket.
  • Page 22 Q1. White Q2. Black Q3. Brown The control of the temperature of the water in the boiler is with a PTC100. The following table shows the values that the PT100 shows for the temperature it detects. The boiler works under pressure and has capacity of 350cc of water. The water for the elaboration of the products is heated here, for espresso coffee and for instant products.
  • Page 23 ºC 100,00 100,39 100,78 101,17 101,56 101,95 102,34 102,73 103,12 103,51 103,90 104,29 104,68 105,07 105,46 105,85 106,24 106,63 107,02 107,40 107,79 108,18 108,57 108,96 109,35 109,73 110,12 110,51 110,90 111,28 111,67 112,06 112,45 112,83 113,22 113,61 113,99 114,38 114,77 115,15 115,54 115,93 116,31 116,70 117,08 117,47 117,85 118,24 118,62 119,01 119,40 119,78 120,16 120,55 120,93 121,32 121,70 122,09 122,47 122,86 123,24 123,62 124,01 124,39 124,77 125,16 125,54 125,92 126,31 126,69...
  • Page 24 A20. Hot water boiler for instant machines The hot water boiler for machines that only have instant products works at atmospheric pressure. The hot water goes to the beaters due to gravity. It is therefore not necessary to have a pump or a deposit for the cold water, unlike the machines for espresso coffee. This machine measures the quantity of water necessary for elaborating the products by the time the EV is open, so it does not have a water meter either.
  • Page 25 A23. Electronic boards All the models in the Zensia range have 4 electronic boards. The PMC module (Payment methods Communication), provides the power supply voltage to the other boards and makes the decisions for the machine to work correctly. The other three control independently a number of other devices in the machine.
  • Page 26 S1. PMC Module S2. IDU Module S3. Infusion Module S4. Cup Module The four boards are linked by one unique 6-way cable called a CAN bus. Two if these lines are used to provide a voltage of 34 volts, another two are for the 8 volt supply and the remaining two are used for communication between the boards.
  • Page 27 A25. Scale filter The espresso models have a scale filter fitted, Purity C150 Quell ST from Brita. The head piece is fixed the cabinet, in the lower part of the machine, whereas the filter is supplied in a box; it is easy to fit, just follow the instructions on the filter.
  • Page 28 INSTALLATION AND START UP 3.1. UNPACKING Only unpack the machine at the moment of installation in the site where it will be used. Dispose of the packaging following the current legal norms for these materials. Safety Norms: Do not touch any mechanisms when you have wet hands or feet. Do not plug in the machine with bare feet.
  • Page 29 3.2.2 Electrical Connexion The machine requires a voltage of 230 Vac (50 Hz). The installation point must have:  A “Euro” approved socket with an earth connection.  A minimum power rating of 2,500 w.  The electrical installation where the machine is sited will be protected with a cut off fuse and have an earth connection.
  • Page 30 3.2.5 Filling the hot water boiler On connecting the machine, the hot water boiler fills automatically. In the espresso coffee machines the following processes take place: The cold water fills the boiler if it is empty. It checks the water meter is working and it fills the boiler with the EV closed, it detects it is full when the water meter stops spinning.
  • Page 31 ERRORS 4.1. ERROR MESSAGES SHOWN ON THE DISPLAY The following table describes the incidents and the corresponding messages that are shown on the display, as well as the codes that in each case are sent by the machine when using communications with protocols VTM or EVADTS.
  • Page 32 Fault detector product exit(fault type2) FAULT IDETECT Switch on the machine OEZN Switch off the machine OEZF Activation of receive infrared OEZI Communication protocol AZKOYEN OEZA Communication protocol EVADTS OEZE Communication VTM in SMS OEZS ► Start configuration MACH. NOT CFG[F401] ECZC Start progr.
  • Page 33 Received software module by EVADTS Description Message on Display EVADTS Received software module by MDB ► Fault in heating system ERR. BOILER ► Error in the temperature sensor ERR. SENSOR TEMP. ► Error in heating element ERR. RESISTENCIA ► Fault in mains water supply ERR.

  • Page 34: Control Points

    4.2. CONTROL POINTS Heating element Measured on the infusion board on connector Between pins 1 and 2 (black and green) shows 0 Vac when the heating element is working. (Assuming the 10A fuse is OK) Between pins 1 and 2 shows 220 Vac when the heating element is not working. Infusion pump Measured on the infusion board on connector Between pins 1 and 4 shows 200 Vac when the pump is working.
  • Page 35 Between pins 1 and 4 shows 5 Vdc when the when the cold water deposit is empty. Dosage micro-switch Measured on the infusion board on connector J9. Between pins 1 and 6 shows 5 Vdc when the dosage is full of coffee. Between pins 1 and 6 shows 0 Vdc when the dosage empty.
  • Page 36 Between pins 6 and 7 shows 0 Vdc when there are no cups between the photocells. Microswitch of the cup lever Measured on the cup holder board on connector J5. Between pins 3 and 7 shows 5 Vdc when the lever is at rest. Between pins 3 and 7 shows 0 Vdc when the lever closes the micro.

  • Page 37: Cleaning And Maintenance

    CLEANING AND MAINTENANCE For each reloading of product, maximum weekly  Waste liquid bucket. Empty and rinse with clean water.  Waste coffee. Empty and rinse with clean water.  Waste liquid tray. Clean with water and dish washing liquid. ...
  • Page 38 Piston filter. Every 20,000 services remove and clean. If necessary, clean with a  non-metallic brush. If necessary, clean holes with a tooth pick. If necessary totally blocked, replace with a new filter.  Infusion filter. Every 20.000 services remove and clean. If necessary, clean with a non-metallic brush.
  • Page 39 WORKING CONDITIONS AND NORMS Optimum results will be obtained from the machine by following the requirements below: Temperatures:  Storage: from -25ºC to +70ºC.  Working: from 0 to +50º C.  Maximum relative humidity without condensation 85%  Norms that it complies with: ...
  • Page 40 DIMENSIONS The measurements are in mm and the weights in Kg. Width Height Depth Weight 1830 1ª 10279 – E 11 - 2011...
