Summarization of Contents
Preface
Declaration
Statements regarding product features and manual usage.
Installation Environment
Guidelines for placing the NVR to ensure proper operation and safety.
1 Overview
1.1 Product Introduction
Introduces the NVR series and its capabilities.
1.2 Key Features
Highlights the main functionalities like network monitoring, multi-screen preview, and recording.
2 GUI
2.1 Before Starting
Essential information before logging into the NVR system, including icon descriptions and common operations.
2.1.3 USB Mouse Operation
Details mouse functions for navigating the NVR interface.
2.4 Shortcut Menu
2.4.1 Channel Config
Guides on adding and managing IP cameras within the NVR system.
2.4.2 Main Menu
Overview of the main interface and its core configuration options.
2.4.3 Playback
Instructions on how to view recorded video files stored on the HDD.
2.4.4 Record
Details on setting up scheduled and event-based recording.
2.4.5 Backup
Steps for backing up recorded video files to a USB drive.
2.4.6 PTZ Control
How to operate PTZ-enabled cameras connected to the NVR.
2.4.7 IPC Config
Configuration settings for connected IP cameras (Image, Encode, etc.).
2.4.8 Info
Accessing system logs and version information for the NVR.
2.4.9 Shutdown
Procedures for restoring, logging out, rebooting, or shutting down the NVR.
2.5 Main Menu
2.5.1 Configuration
Setting up system time, date format, language, and monitor resolution.
2.5.2 Preview
Customizing channel display, time, status, and setting up cyclic playback.
2.5.3 Record
Configuring recording schedules and types, including alarm recording.
2.5.4 Backup
Steps for backing up recorded data using a USB flash drive.
2.5.5 Network
Configuring network settings like DHCP, STATIC IP, PPPoE, DDNS, and email alerts.
2.5.6 HDD
Managing hard disk settings, including formatting and handling full disks.
2.5.7 User
Adding, deleting, modifying users, and changing passwords for NVR access.
2.5.8 Event
Configuring motion detection, video loss alarms, and related actions.
2.5.9 Restore
Restoring the NVR to its factory default settings.
2.5.10 Upgrade
Updating the NVR system firmware using local software.
2.5.11 IPC Config
Advanced configuration for IP cameras, referencing previous sections.
2.5.12 Channel Config
Managing and configuring camera channels, referencing previous sections.
3 Access the NVR in Foscam App
3.1 Download the Foscam APP
Instructions on downloading and installing the Foscam mobile application.
3.2 Create A Foscam Account
Guide to registering for a new Foscam cloud account.
3.3 Add Device in Foscam App
Steps to add the NVR device to the Foscam mobile app.
3.4 Foscam APP Surveillance Window
Navigating the app's main interface for viewing live feeds.
3.5 Watch Live
Viewing live video streams from connected cameras within the app.
3.6 Setting
Accessing advanced NVR settings via the mobile app.
4 Surveillance Software Foscam VMS
4.1 Software Installation
Guide to installing the Foscam VMS software on a PC.
4.2 Create A Local Account
Steps to create a local account for Foscam VMS.
4.3 Add Device
Adding NVR devices to the Foscam VMS software.
4.3.1 LAN Add
Adding devices automatically via LAN discovery.
4.3.2 Manual add
Adding devices manually using UID, DDNS, or IP address.
4.4 Surveillance Software GUI
Overview of the Foscam VMS interface and its main sections.
4.5.1 Basic
Configuring basic device information, time, IP, port, and mail settings.
4.5.3 Application
Configuring motion detection, recording schedules, HDD alarms, and video loss.
4.5.4 System
Managing system upgrades, camera upgrades, factory resets, and reboots.
5 Appendix
5.1 HDD Capacity Calculation
Formula and explanation for determining the required HDD size.
5.2 Specifications
Technical specifications for various NVR models.
