Summarization of Contents
Safety Precautions
Placing the Motor in Service
Instructions for installing, operating, inspecting, and maintaining the motor for safe use.
Using the Motor Safely
Guidelines for safe operation, including PPE and avoiding hazards like fatigue or damaged parts.
Servicing the Motor
Lubrication Recommendations
Recommendations for lubricating the SM4AM motor for optimal performance and life.
Air Supply Installation
Guidelines for installing the air supply line components like FRL and lubricator.
Motor Operation
Flushing the Motor
Step-by-step guide to flush the motor with solvent and oil for sluggish operation.
Dimension Drawings
Model SM4AMB Dimensions
Technical drawings with dimensions for the SM4AMB model.
Model SM4AMANRSS Dimensions
Technical drawings with dimensions for the SM4AMANRSS model.
Assembly Drawing
Parts List
Detailed list of components with part numbers for the SM4AM Series Air Motor.
Maintenance and Troubleshooting
Flushing the Motor
Step-by-step instructions for flushing the motor with solvent and oil to resolve sluggish operation.
Vane Replacement Procedure
Detailed steps for replacing worn vanes, including measurements and techniques.
Disassembly Procedures
General Disassembly Guidelines
Essential precautions and general steps before beginning motor disassembly.
Rear End Plate Disassembly
Specific instructions for removing the rear end plate and associated components.
Front End Plate Disassembly
Specific instructions for removing the front end plate and associated components.
Rotor Removal from Cylinder
Method for safely extracting the rotor from the motor cylinder.
Assembly Procedures
Rear End Plate Assembly
Steps to assemble the rear end plate, gasket, and bearing onto the cylinder.
Front End Plate Assembly
Steps to assemble the front end plate, gasket, and bearing onto the rotor shaft.
Motor Assembly
Complete steps to assemble the rotor, end plates, and seals into the motor.
