DeVilbiss Air Power Company MPG-1420-A Owner's Manual

Devillbiss air power company pressure washer owners manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNERS MANUAL FOR PRESSURE WASHER
•
This product is not equipped with a spark arresting muffler. If the product will be used around flammable
materials, or on land covered with materials such as agricultural crops, forest, brush, grass, or other similar
items, then an approved spark arrester must be installed and is legally required in the state of California. It is
a violation of California statutes section 130050 and/or sections 4442 and 4443 of the California Public
Resources Code, unless the engine is equipped with a spark arrestor, as defined in section 4442, and
maintained in effective working order. Spark arresters are also required on some U. S. Forest service land
and may also be legally required under other statutes and ordinances.
•
Engine exhaust from this product contains chemicals known, in certain quantities, to cause cancer, birth
defects or other reproductive harm.
MPG-1420-A
5/2/96
Model No. WG1420

SPECIFICATION CHART

MODEL
PUMP PRESSURE
FLOW RATE
HORSEPOWER
HOSE
PKG. WEIGHT
INLET WATER PRESSURE
INLET WATER TEMPERATURE
DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615
WG1420
1400 P.S.I. MAX
2.0 G.P.M.
3.5 HP GAS ENGINE
25' HIGH PRESSURE HOSE
55 LBS.
20-145 P.S.I.
60ºC/140ºF Maximum

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPG-1420-A and is the answer not in the manual?

Questions and answers

Related Manuals for DeVilbiss Air Power Company MPG-1420-A

Summary of Contents for DeVilbiss Air Power Company MPG-1420-A

  • Page 1: Specification Chart

    • Engine exhaust from this product contains chemicals known, in certain quantities, to cause cancer, birth defects or other reproductive harm. MPG-1420-A 5/2/96 WG1420 1400 P.S.I. MAX 2.0 G.P.M.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARRANTY STATEMENT ... 3 SAFETY GUIDELINES ... 4 IMPORTANT SAFETY INSTRUCTIONS ... 4-7 GLOSSARY ... 7 GENERAL PARTS IDENTIFICATION ... 8 OPERATING INSTRUCTIONS ... 9 MAINTENANCE & STORAGE ... 10 MAINTENANCE SCHEDULE FOR PUMP ... 10 MAINTENANCE SCHEDULE FOR GAS ENGINE ... 11 TROUBLE SHOOTING GUIDE ...

  • Page 3: Limited Warranty

    LIMITED WARRANTY ONE YEAR FROM DATE OF PURCHASE All merchandise manufactured by DeVilbiss Air Power Company is warranted to be free of defects in workmanship and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and generators used in consumer applications (i.e., personal residential household usage only).

  • Page 4: Safety Guidelines

    Equip areas with fire extin- guishers suitable for gasoline fires. • Never operate pressure washer in an area containing dry brush or weeds. • Store fuel in container approved for gasoline, in a secure location away from work area.
  • Page 5 (open) position. • Become familiar with the operation and c ontrols of the pressure washer. • Keep children away from the pressure washer at all times. • Never defeat the safety features of this product. • Do not operate machine with missing, broken, or unauthorized parts.

  • Page 6: Glossary

    PUMP PRESSURE: Can be adjusted from 100-1400 P.S.I. by turning pressure regulator. PRESSURE WASHER PUMP: Delivers high water pres- sure. Pressure washer pump is shipped with oil. No oil should be added to this pump. 3.5 HP Engine: Gasoline powered engine drives pump.

  • Page 7: General Parts Identification

    5. Quick Connect Coupler- Used to attach water hose to pump. 6. Pressure Washer Gun- Used to control flow of water coming from pump. 7. 3.5 HP Tecumseh Engine- This engine is shipped without oil.

  • Page 8: Operating Instructions

    DO NOT POINT WAND AT SELF OR OTHERS. 8. Pull trigger on gun to start pressure exiting from end of wand. The pressure washer may need to be re- primed if it has not been used for awhile. To do this...

  • Page 9: Maintenance & Storage

    MAINTENANCE AND STORAGE This pressure washer should be stored in such a way to protect it from freezing. *Do not store this unit outdoors or in an area where temperatures will fall below 32ºF. This can cause extensive damage to this unit. Drain as much water as possible as follows: 1.

  • Page 10: Maintenance Schedule For Gas Engine

    Note 1: Change oil every 25 hours when operating under heavy load or in high temperatures. Note 2: Clean more often under dusty conditions. Note 3: Clean exterior with cloth or brush. Do not use high pressure spray to clean pressure washer or engine.

  • Page 11: Accessories/Cleaning Solutions/Service Parts

    ACCESSORIES/CLEANING SOLUTIONS/SERVICE PARTS • Fits DeVilbiss pressure washer gun • High pressure rotating spray for maximum cleaning • Durable ceramic nozzle • Brass thread connections eliminate leakage • Fits DeVilbiss pressure washer wands • 7 in. dia. nylon brush with rotating brush •...
  • Page 12 • Includes wheels and handle for portability • Includes brackets for convenient storage of gun, wand, and hose SERVICE PARTS PW-0021 Quick Disconnect Coupler PW-0024 Pressure Washer Gun PW-0025 Wand/Nozzle, 1.25 mm PW-0038 25' x 1/4" High Pressure Hose PW-0042 Siphon Tube & Filter...

  • Page 13: Service Notes

    SERVICE NOTES...

  • Page 14: Pressure Washer

    OWNERS MANUAL FOR DeVILBISS PRESSURE WASHER Model No. WG1420 Call our Toll Free Number 1-800-888-2468, Ext 2, to obtain the location of the nearest Authorized Service Center for ordering repair parts and for warranty repairs. When ordering repair parts from your local Authorized Service Center, always give the following information: •...
