DeVILBISS AIR POWER COMPANY
OWNERS MANUAL FOR PRESSURE WASHER
Model No. W1217
SPECIFICATION CHART
MODEL
W1217
PUMP PRESSURE
1300 P.S.I. MAX
FLOW RATE
1.7 G.P.M.
VOLTAGE REQUIREMENT
115V/15 AMP/60HZ
MINIMUM FUSE SIZE
15 AMP., TIME DELAY
POWER CORD
35'
HOSE
20' SWIVEL HIGH PRESSURE HOSE
PKG. WEIGHT
17 LBS.
IMPORTANT:
READ AND RETAIN THE SAFETY GUIDELINES AND ALL
INSTRUCTIONS CAREFULLY BEFORE OPERATING
DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615
MPG-1217
6/12/97
Advertisement
Table of Contents
Related Manuals for DeVilbiss Air Power Company MPG-1217
Summary of Contents for DeVilbiss Air Power Company MPG-1217
-
Page 1: Specification Chart
15 AMP., TIME DELAY POWER CORD HOSE 20' SWIVEL HIGH PRESSURE HOSE PKG. WEIGHT 17 LBS. IMPORTANT: READ AND RETAIN THE SAFETY GUIDELINES AND ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615 MPG-1217 6/12/97... -
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE WARRANTY STATEMENT... 3 SAFETY GUIDELINES ... 4 IMPORTANT SAFETY INSTRUCTIONS ... 4-5 GLOSSARY ... 6 GROUNDING INSTRUCTIONS/EXTENSION CORDS ... 6 OPERATING INSTRUCTIONS ... 7 MAINTENANCE & STORAGE ... 8 TROUBLE SHOOTING GUIDE ... 9 ACCESSORIES/CLEANING SOLUTIONS/ SERVICE PARTS ... -
Page 3: Limited Warranty
LIMITED WARRANTY ONE YEAR FROM DATE OF PURCHASE All merchandise manufactured by DeVilbiss Air Power Company is warranted to be free of defects in workmanship and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and generators used in consumer applications (i.e., personal residential household usage only). -
Page 4: Safety Guidelines
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIP- MENT PROBLEMS. To help you recognize this information, we use symbols to the right. Please read the manual and pay atten- tion to these sections. -
Page 5: Important Safety Instructions
FROM SPRAY All sources of energy include the potential for injury. Unsafe operation or maintenance of your pressure washer could lead to serious injury or death to you or others. Reactive force of spray will cause wand to move, and could cause the operator to slip or fall, or misdirect the spray. -
Page 6: Glossary
FLOW RATE: This is the amount of water that passes through your wand. (Usually measured in G.P.M., gallons per minute.). P.S.I.: Unit of measure, pounds per square inch. GROUNDING INSTRUCTIONS & EXTENSION CORDS This product is not equipped with a ground fault interrupter. -
Page 7: Operating Instructions
(about 15 seconds). Verify that there are no water leaks. 5. Verify that the pressure washer switch is in the "Off" position. Plug the power cord into the G.F.C.I. Protected outlet. (Push reset on G.F.C.I.). -
Page 8: Maintenance & Storage
2. Clean the nozzle with the nozzle cleaning tool. This pressure washer should be stored in such a way to protect it from freezing. Do not store this unit outdoors or in an area where temperatures will fall below 32ºF. -
Page 9: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM Motor will not start and there is no humming sound Power source circuit continues to trip or blow fuses Motor hums but will not start Unit does not reach required pressure Units cycles automatically without triggering the gun. Continuous tripping of a G.F.C.I. -
Page 10: Accessories/Cleaning Solutions/ Service Parts
• Adjustable- for angled use • 2 ft. extension for added reach • Requires adaptor that is included with Pressure Washer (K-0369) • 7 in. x 3 in. soft nylon bristles • Tapered for cleaning in tight spots • 2 ft. extension for added reach •... -
Page 11: Service Parts
SERVICE PARTS Detergent Dispenser Gun/Hose Adjustable Spray Wand Hose Retainer Clip 1. Pressure Washer 2. Gun/Hose 3. Middle Extension Wand 4. Adjustable Spray Wand 5. Detergent Dispenser 6. Low Pressure Attachment Adaptor (for use when attaching either of the brush kit) 7. -
Page 12: Pressure Washer
DeVILBISS AIR POWER COMPANY OWNERS MANUAL PRESSURE WASHER Call our Toll Free Number 1-800-888-2468, Ext 2, then 1, to obtain the location of the nearest Authorized Service Center for or- dering repair parts and for warranty repairs. When ordering repair parts from your local Authorized Service Cen- ter, always give the following information: •...
