Summarization of Contents
2. Part Description
Thru-beam Type (Front & Side Sensing)
Details components and operation modes for EX-21 and EX-23 thru-beam sensors.
Other Sensor Types (Retroreflective, Diffuse, Convergent, Narrow-view)
Illustrates parts for EX-29, EX-22, EX-26, EX-28, and EX-24 sensor types.
3. Mounting
3-1 Mounting the Sensor
Instructions for mounting the sensor using M3 screws and recommended torque.
3-2 Mounting Brackets (Optional)
Details optional sensor mounting brackets for different sensor types and their specifications.
3-3 Mounting Spacer (Optional)
Describes how to mount the optional spacer MS-EX20-FS for front sensing type sensors.
3-4 Installation Interval
Guidelines for determining the minimum installation interval between sensors using deviation diagrams.
3-5 Mounting Glossy Surfaces (Retroreflective EX-29)
Recommendations for mounting the EX-29 retroreflective sensor when detecting glossy objects.
5. Adjustment
5-1 Beam Alignment
Procedure for aligning the emitter and receiver or sensor and reflector for optimal sensing.
5-2 Sensitivity Adjustment
Steps for adjusting sensor sensitivity for diffuse, convergent, and narrow-view types.
7. Option
7-1 Slit Mask (Thru-beam EX-21/EX-23)
Details the use, specifications, and mounting of slit masks for EX-21 and EX-23 sensors.
7-2 Reflector / Refractive Tape (Retroreflective EX-29)
Lists optional reflectors and tapes for EX-29 sensors, including distances and specifications.
