6.5

Mechanical specifications

Refer to Figure 7 for detailed physical dimensions. See Section 8.4, "Drive mounting."
Height (max):
Width (max):
Depth (max):
Weight (max):
H
// T -Z-
REF
S
[1]
A
-Z-
M
U -X-
P
F
[1]
E
Figure 7. Mounting configuration dimensions
Cheetah NS FC Product Manual, Rev. A
1.028 in
4.010 in
5.787 in
1.76 pounds
B
J
L
R REF
Notes:
N -X-
[1]
C
-X-
D
26.11 mm
101.85 mm
146.99 mm
0.800 kilograms
K
-Z-
Mounting holes are 6-32 UNC 2B, three
on each side and four on the bottom.
Max screw penetration into side of drive
is 0.15 in. (3.81 mm). Max screw
tightening torque is 6.0 in-lb (3.32 nm)
with minimum full thread engagement of
0.12 in. (3.05 mm).
Dimension Table
Inches Millimeters
A 1.028 max 26.10
B 5.787 max 147.00
C 4.000 ± .010 101.60
D 3.750 ± .010 95.25
E 0.125 ± .010 3.18
F 1.750 ± .010 44.45
H 1.122 ± .020 28.50
J 4.000 ± .010 101.60
K 0.250 ± .010 6.35
L 1.638 ± .010 41.60
M 0.181 4.60
N .040 1.02
P 1.625 ± .020 41.28
R 1.618 41.10
S 0.276 ± .040 7.00
T .015 max 0.38
U .015 max 0.38
max
max
± .25
± .25
± .25
± .25
± .50
± .25
± .25
± .25
± .50
± 1.02
max
max
35
