Cisco AIR-AP-T-RAIL-F Mounting Instructions

Access Point Mounting Instructions
Published: November 8, 2010
Revised: February 07, 2019
Contents
•
•
•
•
•
•
•
•

Introduction

These mounting instructions describe the steps for mounting supported Cisco Aironet series access
points in several configurations, including on a suspended ceiling, on a hard ceiling or wall, on an
electrical or network box, and above a suspended ceiling.

Mounting Hardware

Mounting hardware for access points consists of brackets, which connect to the bottom of the access
point, and ceiling grid clips, which connect the bracket to a suspended ceiling. The bracket that you need
depends on the mounting location for the access point. The ceiling grid clip that you need depends on
the type of suspended ceiling where you need to install the access point. You don't need ceiling grid clips
if you are mounting the access point to a hard-surface ceiling or a wall.
Cisco Systems, Inc.
www.cisco.com
Introduction, page 1
Mounting Hardware, page 1
Mounting an Access Point Below a Suspended Ceiling, page 5
Mounting an Access Point on a Hard Ceiling or a Wall, page 6
Mounting an Access Point to a Network or Electrical Box, page 8
Mounting an Access Point Above a Suspended Ceiling, page 9
Grounding an Access Point, page 10
Securing an Access Point, page 12
