Tyan S1952DLU
Thunder X
Motherboard User's Manual
Revision 1.0
Copyright © Tyan Computer Corporation, 1998. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from Tyan
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are property of their respective companies including, but not limited to the
following.
AMI BIOS is a trademark of American Megatrend Incorporated.
Windows is a trademark of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
INTEL, Pentium II, Celeron, Xeon are trademarks of Intel Corporation.
S1952 Thunder X is a trademark of TYAN Computer Corporation.
Information contained in this publication has been carefully checked for accuracy and
reliability. In no event will Tyan Computer be held liable for any direct or indirect,
incidental or consequential damage, loss of use, loss of data, or other malady resulting
from errors or inaccuracies of information contained in this manual. The information
contained in this document is subject to change without notice.
PRINTED IN USA.
S1952DLU Thunder X
1-1

Advertisement

Table of Contents
loading

Summary of Contents for TYAN THUNDER X

  • Page 1 Information contained in this publication has been carefully checked for accuracy and reliability. In no event will Tyan Computer be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data, or other malady resulting from errors or inaccuracies of information contained in this manual.
  • Page 2: Table Of Contents

    Connecting Com and Printer Ports........... 2-25 Connecting USB and PS/2 ports............2-26 3. BIOS Configuration..................3-1 Main Setup................... Advanced CMOS Setup..............Advanced Chipset Setup..............3-12 Power Management Setup..............3-18 Plug and Play Setup................3-22 Peripheral Setup.................. 3-27 Supervisor and User Security............3-30 http://www.tyan.com...
  • Page 3 Hard Drive / Floppy Drive Issues............. BIOS Issues..................Driver Issues..................Miscellaneous Issues................. Appendix B - Adaptec Ultra2 LVD SCSI............B-1 Introduction..................Setting Up SCSI Peripherals.............. Connecting SCSI Peripherals............Additional Termination Information..........Installing AIC7896 SCSI Software............ Troubleshooting................. Appendix C - Glossary..................C-1 S1952DLU Thunder X...
  • Page 4: Introduction

    UltraDMA/33, onboard floppy controller, onboard 32-bit PCI Ultra2 dual channel SCSI, and onboard high speed I/O. Flexibility and expendability have been designed into the Thunder X. With I/O and drive controller support built onboard, the one AGP slot, six PCI and one ISA slot (one shared, seven usable slots) are free for numerous add-on expansion cards.
  • Page 5: Icons

    Remember to take a look at TYAN Computer’s web site located at http://www.tyan.com. There you can find information on all of TYAN’s products along with FAQs, distributors list, drivers, and BIOS setting explana- tions. Icons In order to help you navigate this manual and set up your system, we have added several icons to our format.
  • Page 6: Hardware Specifications/Features

    •Intel LANDesk Client Manager software included •Chassis intrusion detection capable. •Power recovery after interrupt Expansion Slots •One 32-bit AGP slot. •Six 32-bit PCI Bus Master slots. •One 16-bit ISA slots. •One shared PCI-ISA / seven usable slots. http://www.tyan.com...
  • Page 7 (up to 2.88MB). •Two ATX serial ports (16550 UARTs). •One ATX ECP/EPP parallel port. •One IR (InfraRed) I/O interface port. •Two ATX USB rev 1.2 (universal serial bus) ports. •One ATX PS/2 mouse connector. •One ATX PS/2 keyboard connector. S1952DLU Thunder X...
  • Page 8: Software Specifications

    If your dealer is unable to assist you: 1) try our web page: http:// www.tyan.com 2) user newsgroup: alt.comp.periphs.mainboard.tyan 3) technical support phone line:...
  • Page 9: Returning Merchandise For Service

    Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid, or hand-carried to the manufacturer. TYAN will pay to have the board shipped back to you. S1952DLU Thunder X...
  • Page 10 Chapter 1 Introduction This page has been intentionally left blank. http://www.tyan.com 1-10...
  • Page 11: Board Installation

    System Management & Driver CD (Intel LANDesk) 2.2 Installation You are now ready to install your motherboard. The mounting hole pattern of the S1952DLU matches the ATX system board specifications. Your chassis should be that of an extended ATX mainboard form factor. S1952DLU Thunder X...
  • Page 12 If you do not ground yourself, you risk zapping the motherboard or adapter card. Subsequent problems may not arise immediately because electrostatic discharge damage, unlike physical damage, causes the device to fail over time. http://www.tyan.com...
  • Page 13: Setting Jumpers

    CPU speed, Infrared, and external connector pin assignments, among others. The miniature motherboard maps will help you locate the jumpers on your board. A full-page map of the motherboard can be found on the next two pages. S1952DLU Thunder X...
  • Page 14: Map Of Motherboard Jumpers

    PCI Slot 2 JP23 PCI Slot 3 Adaptec AIC-7896N 3V Lithium Battery PCI Slot 4 JP15 JP28 JP35 Intel JP19 82371EB PCI Slot 5 JP17 JP36 JP20 JP11 JP13 PCI Slot 6 APIC ISA Slot 1 JP12 JP14 FAN4 JP27 http://www.tyan.com...
  • Page 15 PS/2 ports Slot2 slots Intel 4 DIMM IDE and Floppy 82443GX slots connectors AMIBIOS 1 ISA Slot Intel Adaptec 82371EB APIC AIC-7896N (PIIX4e) S1952DLU Thunder X...
  • Page 16: Hardware Cmos & Password Reset

    In order to adjust the speed of the CPU, change the jumper settings according to the chart below. The clock speed settings control the clock multiplier (CPU Core / Bus Ratio). Tyan does not recommend operating CPUs, memory, or PCI Bus at higher than rated speed. Tyan takes no responsibility for any problems related to overclocking any bus or component on the system board.
  • Page 17 IR T ra n s m it V C C N o C o n n e c t N o C o n n e c t JP20 To p Bottom Pin1 Pin2 Top Pin Pin17 Bottom Pin J10 Side View S1952DLU Thunder X...
  • Page 18: Jumper Settings

    G N D S E C UR E N o C o nn ec t C H IS IN T G N D N o C o n nec t - Wake-On LAN (Jumper JP15) - Wake-On Ring (Jumper JP19) http://www.tyan.com...
  • Page 19 N o S pee d D et ec t Fan5 (CPU2) N o S pee d D et ec t Fan6(CPU1) N o S pee d D et ec t FAN2 FAN1 FAN5, FAN 6 FAN3 JP21 JP15 JP35 JP19 JP36 FAN4 JP27 JP28 S1952DLU Thunder X...
  • Page 20: Soft Power Connector

    Speaker Connector Installation The Thunder X provides a 4-pin header to connect the external speaker. The speaker should be connected to pins 1-4 of jumper JP35. As default, pins 3-4 of jumper JP35 are connected to the internal buzzer.
  • Page 21: Chassis Intrusion Alarm Connector

    The Thunder 100 uses flash memory to store BIOS programs. It can be updated as new versions of the BIOS become available. You can upgrade your BIOS easily using the flash utility (see page 3-31). JP17 S1952DLU Thunder X 2-11...
  • Page 22: Memory Installation

    Because of this, your memory may not work correctly in a TYAN board though it may work well in a competitor’s board. Many of our competitors do not adhere to the strict tolerances required for high performance.
  • Page 23 Place the DIMMs in an antistatic bag as soon as you remove them to avoid static damage. The Thunder X uses a 64-bit data path from memory to CPU and can accom- modate up to 1024MB of SDRAM (2GB of SDRAM has not been validated).
  • Page 24 64MBx1 64MBx1 64MBx1 192MB 128MBx1 64MBx1 64MBx1 256MB 128MBx1 128MBx1 64MBx1 320MB 128MBx1 128MBx1 128MBx1 384MB 256MBx1 128MBx1 128MBx1 512MB 256MBx1 256MBx1 128MBx1 640MB 256MBx1 256MBx1 256MBx1 768MB 256MBx1 256MBx1 256MBx1 256MBx1 1024MB 512MBx1 512MBx1 512MBx1 512MBx1 2048MB http://www.tyan.com 2-14...
  • Page 25: Cache Memory

    Both types of CPUs provide the user with the same performance, and both types can be installed in the Pentium II slot on the Thunder X. Passive Cooling Processor Active Cooling Processor...
  • Page 26 CPU slots (see Figure 2-7 below). Follow the instructions provided by the case manufacturer for proper installation guidelines. TYAN recommends that you use only one screw to hold down the motherboard. The rest of the mounting holes should be used for the plastic standoffs.
  • Page 27 Warning: Do warning NOT overtighten as you may damage the retention brace and/or the motherboard. Your fastened retention braces should look like Figure 2-9 below.. Figure 2-9 S1952DLU Thunder X 2-17...
  • Page 28 CPU (See Figure 2-11). In or- der to attach the handle, slide the handle over the top side of the CPU until the handle hook snaps into place (See Figure 2-12) igure 2-11 Figure 2-12 http://www.tyan.com 2-18...
  • Page 29 Press down firmly on the handle until the CPU is securely in the slot (see Figure 2-14 below). Be sure to screw the handles onto the retention braces after CPU is inserted. Figure 2-14 S1952DLU Thunder X 2-19...
  • Page 30 FAN1) on the motherboard. Plug the CPU’s fan cable into the fan connector. There will be a plastic clip assembly similar to that of the ATX power connector that will force you to connect the fan cable correctly (see Figure 2-16 below). Figure 2-16 http://www.tyan.com 2-20...
  • Page 31: Add-On Card Installation

    ! ! ! ! ! If you are using a single CPU, Tyan recommends that the CPU be installed in the CPU2 slot. The default slot on the Thunder X is the CPU2 slot. If you important! choose to install your CPU in the CPU1 slot, you will not be able to monitor your CPU with your system management software.
  • Page 32: Power Supply Installation

    Board Installation 2.7 Power Supply Installation Connecting the Power Supply Tyan recommends using an ATX power supply that conforms to industry standard revision 2.01. The Thunder X motherboard comes equipped with two onboard power connectors. This allows the option of...
  • Page 33: Connecting Ide / Scsi Cables And Devices

    IDE cable to the hard drive. Figure 2-20 shows the IDE cable properly connected to the motherboard. The Thunder X motherboard is Pin 1 equipped with three onboard SCSI connectors - two Ultra 2 SCSI channels and one Single- Ended SCSI channel.
  • Page 34: Connecting Floppy Drives

    In most cases, there will be a key pin on the cable which will force you to connect the cable properly. Figure 2-21 http://www.tyan.com 2-24...
  • Page 35: Connecting Com And Printer Ports

    The Com and Printer ports, as well as the other ports, are labeled. Note: Only TYAN cables will work on this motherboard. If you are using an existing case with old cables, your system will not function properly. Use only TYAN-approved cables.
  • Page 36: Connecting Usb And Ps/2 Ports

    It is fast enough to support video transfer, and is capable of supporting up to 127 daisy-chained peripheral devices. Figure 2-23 on the next pate shows the PS/2 ports on the left and USB ports on the right. http://www.tyan.com 2-26...
  • Page 37 If you do encounter problems, your dealer will be able to help you, or you can consult one of our many technical support resources (see page 1-8). S1952DLU Thunder X 2-27...
  • Page 38 Chapter 2 Board Installation This page has been intentionally left blank. http://www.tyan.com 2-28...
  • Page 39: Bios Configuration

    Primary IDE Slave Auto Secondary IDE Master Auto Secondary IDE Slave Auto Auto-Detect Hard Disks [ Enter ] Boot Sector Virus Protection Disabled Previous Item Next Item Select Menu ESC:Exit Enter:Select F5:Setup Defaults F6:Original Values F10:Save & Exit S1952DLU Thunder X...
  • Page 40: Main Setup

    Primary IDE Master Auto Primary IDE Slave Auto Secondary IDE Master Auto Secondary IDE Slave Auto Auto-Detect Hard Disks [ Enter ] Boot Sector Virus Protection Disabled Previous Item Next Item Select Menu ESC:Exit Enter:Select F5:Setup Defaults F6:Original Values F10:Save & Exit http://www.tyan.com...
  • Page 41 Maximum Capacity CD-ROM: Use for ATAPI CD-ROM drives LBA Mode Block Mode Double click [AUTO] to Fast Programmed I/O Modes set all HDD parameters 32 Bit Transfer Mode ON automatically ESC:Back Enter:Select :Select Items F5:Setup Defaults F6:Original Values S1952DLU Thunder X...
  • Page 42 (when you select Auto for Type), or you can turn the modes On or Off yourself. Block Mode: If On, Block Mode automatically detects the optimal number of block read/writes per sector that the drive can support. http://www.tyan.com...
  • Page 43 . ) r S1952DLU Thunder X...
  • Page 44: Boot Sector Virus Protection

    Load Optimal Settings [ Enter ] Load configuration Load Fail Safe Settings [ Enter ] settings giving Load Original Values [ Enter ] highest performance. Previous Item Next Item Select Menu ESC:Exit Enter:Select F5:Setup Defaults F6:Original Values F10:Save & Exit http://www.tyan.com...
  • Page 45: Advanced Cmos Setup

    F lo p py A c c es s C o nt ro l R ead -W rite R ea d-W rit e H ard D is k A c c es s C o n tro l R ead -W rite R ea d-W rit e S1952DLU Thunder X...
  • Page 46: Advanced Setup

    . n i < > l t f i t i a v i r g i f v i r e t f o l l v i r . n i , t o < > l http://www.tyan.com...
  • Page 47 This option specifies the read-write access that is set when booting from a hard disk drive. The settings are Read-Write or Read-Only. S.M.A.R.T. for Hard Disks Set this option to Enabled to permit AMIBIOS to use the SMART (System S1952DLU Thunder X...
  • Page 48 The contents of this memory segment are copied from the BIOS ROM to system RAM for faster execution. The settings are Enabled or Disabled. The Optimal default setting is Enabled. http://www.tyan.com 3-10...
  • Page 49: Mps Revision

    The ROM area not used by ISA adapter cards is allocated to PCI adapter cards. The settings are: i t t a s i r e t o i t t t i r . y r S1952DLU Thunder X 3-11...
  • Page 50: Advanced Chipset Setup

    M etho d o f M e m o ry D e t e c t io n A u to & S P D A u t o & S P D D R A M In t egrit y M o de A uto A ut o http://www.tyan.com 3-12...
  • Page 51: Usb Function

    C P U B us F requ enc y A ut o A ut o * Setting option not selectable. USB Function Set this option to Enabled to enable USB (Universal Serial Bus) support. The settings are Enabled or Disabled. S1952DLU Thunder X 3-13...
  • Page 52 The settings are Disabled, 32, 64, 96, 128, 160, 192, or 224. Multi-Trans Timer (Clks) This option specifies the multi-trans latency timings (in PCI clocks) for devices in the computer. The settings are Disabled, 32, 64, 96, 128, 160, 192, or 224. http://www.tyan.com 3-14...
  • Page 53 DRAM system memory access cycle when SDRAM system memory is installed in this computer. The settings are Auto, 2 SCLKs, or 3 SCLKs. Power Down SDRAM If this option is set to Enabled, the SDRAM Power Down feature is enabled. The settings are Enabled or Disabled. S1952DLU Thunder X 3-15...
  • Page 54 Enabled or Disabled. 8bit I/O Recovery Time This option specifies the length of a delay inserted between consecutive 8-bit I/O operations. The settings are Disabled and from 1 to 8 Sysclk (system clocks) in increments of one. http://www.tyan.com 3-16...
  • Page 55 This option provides selective CPU Bus Frequency; however, it is strongly recommended that the default setting (Auto) be selected. Unpredictable situations may arise if the Intel default CPU bus speed is not used. The settings are Auto, 66.8MHz, 68.5MHz, 75MHz, 83.3MHz, 100MHz, 103MHz, or 112MHz. S1952DLU Thunder X 3-17...
  • Page 56: Power Management Setup

    D is abled S lo w C lo c k R at io 50 % - 62 .5% 5 0% - 6 2.5 % D is p lay A c t iv it y Igno re Igno re http://www.tyan.com 3-18...
  • Page 57 Green PC Monitor Power State This option specifies the power state that the green PC-compliant video monitor enters when AMIBIOS places it in a power saving state after the S1952DLU Thunder X 3-19...
  • Page 58 This option defines the length of time that the system, while in Standby mode, must be inactive before it enters Suspend mode. The settings are Disabled and from 4 minutes to 508 minutes, in increments of 4 minutes. http://www.tyan.com 3-20...
  • Page 59 If this option is Enabled, the CPU fan will turn off when the system is in Suspend mode. If Disabled, the CPU fan will remain on while the system is in Suspend mode. The settings are Enabled or Disabled. S1952DLU Thunder X 3-21...
  • Page 60: Plug And Play Setup

    Configure PCI / Plug Plug and Play Setup [ Enter ] and Play features Peripheral Setup [ Enter ] Change Language Setting English Previous Item Next Item Select Menu ESC:Exit Enter:Select F5:Setup Defaults F6:Original Values F10:Save & Exit http://www.tyan.com 3-22...
  • Page 61 F irs t -Las t F irs t -Las t B IO S D ev no de f o r S had o w R A M D is abled D is abled * Setting option is not selectable S1952DLU Thunder X 3-23...
  • Page 62 AMIBIOS automatically determines the correct setting (including using the onboard controller if no offboard controller card is detected). This option forces IRQ 14 and 15 to a PCI slot on the PCI local bus. This is necessary to http://www.tyan.com 3-24...
  • Page 63 PCI and PnP devices. The settings are ISA/EISA or PCI/PnP. Reserved Memory Size This option specifies the size of the memory area reserved for legacy ISA adapter cards. The settings are Disabled, 16K, 32K, or 64K. S1952DLU Thunder X 3-25...
  • Page 64 The settings are First-Last or Last-First. BIOS Devnode for Shadow RAM This option is used for some add-on card ROMs which do not claim the correct memory range that they occupy. The settings are Disabled or Enabled. http://www.tyan.com 3-26...
  • Page 65: Peripheral Setup

    P aralle l P o rt IR Q *P arallel P o rt D M A C hann el N / A N / A O nbo ard ID E B o t h B o th S1952DLU Thunder X 3-27...
  • Page 66: Onboard Serial Port

    . e t l l a l l u http://www.tyan.com 3-28...
  • Page 67: Ir Receiver Pin

    DMA channel used by the parallel port. The settings are 0 through 7 in increments of one. Onboard IDE This option specifies the IDE channel used by the onboard IDE controller. The settings are Disabled, Primary, Secondary, or Both. S1952DLU Thunder X 3-29...
  • Page 68: Supervisor And User Security

    When you select the Supervisor Security option, a dialog box (shown below) will appear, allowing you to enter a password. You may either type the pass- word in, or click on the onscreen buttons. Your password must be between one and six characters long. http://www.tyan.com 3-30...
  • Page 69: Language Utility

    You will be prompted to press <F1> to run Setup. You may check your settings at this time, or simply save and exit the program. S1952DLU Thunder X 3-31...
  • Page 70 Chapter 3 BIOS Configuration This page has been intentionally left blank. http://www.tyan.com 3-32...
  • Page 71: System Resources

    Displayed error messages, in most cases, allow the system to continue to boot. Displayed error messages are described on pages 74-75. See the top of the next page for the beep code chart. S1952DLU Thunder X...
  • Page 72: Troubleshooting System Problems

    BIOS ROM chip is bad. The system probably needs a new BIOS ROM chip. 11 times... reseat the cache memory on the motherboard. If it still beeps, replace the cache memory. 4, 5, 7, or 10 times... the motherboard must be replaced. http://www.tyan.com...
  • Page 73: Displayed Error Messages

    . y r f i d r e f u l i o i t e z i f i d r e f i l i t . y t S1952DLU Thunder X...
  • Page 74 . t o : s i y t i y t i . y r : s i y t i y t i . s s y t i http://www.tyan.com...
  • Page 75: Appendix A - Frequently Asked Questions

    Frequently Asked Questions Portions of this appendix can be found in more detail at Tyan’s website (www.tyan.com) under the FAQ section. To help alleviate any common problems associated with the installation of new hardware or software, we are providing useful suggestions which should help you get your system running in no time.
  • Page 76 Q: All I get are beep codes. What do they mean? A: Fatal errors, which halt the boot process, are communicated through a series of audible beeps. If AMIBIOS POST can initialize the system video display, it displays the error message. Displayed error messages, in most http://www.tyan.com...
  • Page 77: Video Issues

    Q: Does my operating system support AGP? A: Currently, only Windows 98 and Windows NT 5.0 will have built-in support for AGP. Some AGP cards require Windows 95 OSR2.1 or a special driver from Intel. Please check with your graphics vendor for more details. http://www.tyan.com...
  • Page 78: Cpu Issues

    IDT CPUs are not supported in dual mode. Q: Can I overclock my CPU? A: Overclocking your CPU is not recommended by TYAN. Because TYAN does not recommend this, we are not able to provide technical support to those who are overclocking their CPUs. Overclocking your CPU may cause damage to your system board and/or shorten the life expectancy of your CPU.
  • Page 79: Memory Issues

    A: It isn’t a good idea to mix brands, types, and speeds of RAM because all Tyan motherboards are produced with performance in mind. When we talk about performance, it goes hand in hand with tolerances which must be met in order to reach the performance levels expected of high quality peripher- als.
  • Page 80: Hard Drive / Floppy Drive Issues

    If you are unsure of proper cable orienta- tion on the motherboard end, please refer to Chapter 2 - Map of Motherboard Jumpers on page 2-4. http://www.tyan.com...
  • Page 81: Bios Issues

    Tyan motherboards use either AMI or Award BIOS. The BIOS version can be found at bootup just below the left hand corner logo. Ignore all version numbers that do not start with “TYN”. Tyan BIOS versions begin at startup with the following line: TYN [motherboard model] Vx.xx MM/DD/YY...
  • Page 82: Driver Issues

    7896 thus causing the blue screen error. Even if you manually tell NT to use the driver on the floppy disk provided by Tyan, NT will still use the older driver from the CD-ROM. At this time there is no solution which can correct the CD-ROM boot install of NT 4.0.
  • Page 83 3. If you have replaced the motherboard and the problem still persists, it’s probably not the motherboard at fault. There is a very, very slim chance that two consecutive boards will be bad..however, if it’s exhibiting the same symptoms, check with your peripheral vendors for possible conflicts and compatibility issues. http://www.tyan.com...
  • Page 84 Appendix A Frequently Asked Questions This page has been intentionally left blank. http://www.tyan.com A-10...
  • Page 85: Appendix B - Adaptec Ultra2 Lvd Scsi

    LVD Ultra2 SCSI bus, the Ultra2 devices automatically switch to single-ended mode. When an Ultra2 SCSI device operates in single- ended mode it is subject to the cable distance limitations and signal noise problems of that interface. S1952DLU Thunder X...
  • Page 86: Board Layout

    SCSI (50-pin) connector to simplify connecting single-ended devices. Board Layout The following diagram shows the major SCSI connectors and jumpers for the motherboard. Floppy Drive Secondary IDE Primary IDE Ultra 2 SCSI Ch A JP22 SCSI SE Ultra 2 SCSI Ch B JP23 Adaptec AIC-7896N http://www.tyan.com...
  • Page 87: Setting Up Scsi Peripherals

    Using an Ultra SCSI terminator on an LVD Ultra2 SCSI bus will force the bus to single-ended mode, limiting the speed and cable distance. For this reason be sure that you have the necessary Ultra2 cable or terminator before installing the Ultra2 SCSI devices. S1952DLU Thunder X...
  • Page 88: Connecting Scsi Peripherals

    Connect to Motherboard Ultra2 SCSI connector Connect to Ultra2 Peripherals Built-in Terminator STEP 2: Plug the long end of the cable(s) to the Ultra2 connector(s) on the motherboard - Channel A or B. (refer to the board layout for connector location). http://www.tyan.com...
  • Page 89 STEP 1: Locate a 68-pin or 50-pin internal Ultra SCSI cable. Connect to Fast/Wide Ultra Peripheral (Terminated) Connect to Motherboard Connect to Fast/Wide Ultra 68-pin connector Peripheral (Not Terminated) Connect to Fast/Ultra Narrow Connect to Fast/Ultra Narrow Connect to Motherboard Peripheral (Terminated) Peripheral (Not Terminated) 50-pin connector S1952DLU Thunder X...
  • Page 90 Each Ultra2 SCSI peripheral connects to the next in a daisy chain. Therefore each external peripheral will require an external cable. As an option, Tyan provides an external Ultra2 SCSI connector that can be inserted in an expansion slot. The cable end of the external SCSI connector...
  • Page 91: Additional Termination Information

    When installed in multiple computer configurations, i.e. clusters, you can force the motherboard to enable termination even when power to the com- puter is OFF. This would enable the other computers in the cluster to continue to operate the shared SCSI devices even when the computer S1952DLU Thunder X...
  • Page 92: Installing Aic7896 Scsi Software

    STEP 3: Insert the 7800 Family Manager Set setup diskette in your floppy disk drive, then click OK. STEP 4: Follow the instructions that appear onscreen. Computers with Windows NT Installed STEP 1: Turn on all external peripherals and then the computer. STEP 2: Start Windows NT on your computer. http://www.tyan.com...
  • Page 93: Troubleshooting

    Are all SCSI cables and power cables properly connected? Does each device on the SCSI bus have a unique SCSI ID? Does the total SCSI cable length exceed the maximum allowable length? Is the SCSI chain properly terminated? S1952DLU Thunder X...
  • Page 94 Appendix B Adaptec Ultra2 LVD SCSI This page has been intentionally left blank. http://www.tyan.com B-10...
  • Page 95: Appendix C - Glossary

    CD-ROMs and tape drives to be configured as master or slave devices, just like hard drives. form factor was designed to replace the AT form factor. It improves on the AT design by rotating the board ninety degrees, so that the IDE S1952DLU Thunder X...
  • Page 96 512KB, while you may have as much as 1GB of regular memory. Cache size refers to the physical size of the cache onboard. This should not http://www.tyan.com...
  • Page 97 Dynamic RAM is a widely available, very affordable form of RAM which has the unfortunate tendency to lose data if it is not recharged regularly (every few milliseconds). This refresh requirement makes DRAM slower three to ten times slower than non-recharged RAM such as SRAM. S1952DLU Thunder X...
  • Page 98 PCB (personal computer board) or motherboard. The standard form factors are the AT and ATX, although TYAN also makes some Baby-AT boards. Global timer is an onboard hardware timer, such as the Real Time Clock.
  • Page 99 (PCI Programmable Input/Output) modes are the data transfer modes used by IDE drives. These modes use the CPU for data transfer (DMA channels do not). PCI refers to the type of bus used by these modes to communicate with the CPU. S1952DLU Thunder X...
  • Page 100 By transferring data alter- nately from one set of addresses, and then the other, SDRAM cuts down on the delays associated with non-synchronous RAM, which must close one address bank before opening the next. http://www.tyan.com...
  • Page 101 The system “listens” to network activity even when the computer is off. Special “wake-up” packets sent by another computer causes the adapter to signal the computer to power up and run a predefined program. S1952DLU Thunder X...
  • Page 102 Zero Insertion Force sockets make it possible to insert CPUs without damaging the sensitive pins. The CPU is lightly placed in an open ZIF socket, and the metal lever pulled down. This shifts the processor over and down, guiding it into place on the board. http://www.tyan.com...
  • Page 103 Replace ONLY with the same or equivalent type recommended by manufacturer. Dispose of used batteries according to manufacturer instructions. Note: The joystick port maximum output rating is 9 amperes at 5 volts. Document # D1329-100 S1952DLU Thunder X...
